Description
The 786 series general purpose Pulse Transformer for line coupling, impedance-matching and isolating. This transformer can also be used in small isolated power supplies or as common-mode chokes in filtering applications.
- 4 Configurations
- Primary inductance to 10mH
- 1kVrms Isolation
- Industry standard pin-out
- Surface mount option
- UL94V-0 package materials
- Low profile
- Toroidal construction
- Fully encapsulated
Applications
Power Management, Industrial
Warnings
Market demand for this product has caused an extension in leadtimes. Delivery dates may fluctuate. Product exempt from discounts.
Product details
| Turns Ratio: 2:1 |
| Inductance: 2mH |
| DC Resistance: 0.6ohm |
| ET Constant: 20Vµs |
| Isolation Voltage: 1kV |
| Product Range: 78604/1C Series |
Other details
| Brand | MURATA POWER SOLUTIONS |
| Part Number | 78604/1C |
| Quantity | Each |
| Technical Data Sheet EN |  |
