Description
PTZOptics PT30X-4K Overview
- 1Description
- 2
- 3Auto-Tracking PTZ Camera
- 4Multiple Output Options
- 5Pan, Tilt, Zoom, Track
- 6Mounting Options
- 7Control Your Way
- 8Software App
By Photo's
Jennifer Hahn
Add a high-resolution streaming and tracking camera to your classroom, house of worship, or conference room for remote meetings with software such as Skype, Microsoft Teams, or Zoom with the gray
Move 4K SDI/HDMI/USB/IP PTZ Camera with 30x Optical Zoom from
PTZOptics. The Move 4K camera captures resolutions up to UHD 4K60, and it features auto-tracking for presentations where your subject moves around the room, great for education, how-to, and corporate environments without the need for an operator. Its wide dynamic range, 3D noise reduction, and low-bandwidth, high-quality NDI|HX 3 capabilities provide a sharp, consistent image, even in low light.
Auto-Tracking PTZ Camera
The Move 4K is the latest PTZ camera from PTZOptics, featuring auto-tracking for a more intelligent video production workflow. The Move 4K is capable of 4K60 (1080p60 over SDI), future-proofing your technology investment while still accommodating HD and Full HD video resolutions equipment. The Move 4K offers high performance in low-light scenarios, PoE+ capabilities, and a built-in tally light.
Multiple Output Options
Every Move 4K camera features SDI, HDMI, USB, and IP output, and comes native with NDI|HX for unparalleled performance and versatility. The Move 4K offers built-in auto-tracking capabilities with no need to run software on another computer, freeing teams of the need for a camera operator.
Pan, Tilt, Zoom, Track
Control your production from behind the scenes or right in front of them. The Move 4K's auto-tracking can lock into a specific person, even while other people are in frame. Users can switch between on-stage presenters with the click of a button.
The Move 4K can track subjects up to 300' away. In addition to the auto-tracking features, users will also have access to the latest Web UI, updated to provide everything you need in one simple menu. Almost every feature in the Web UI has a tutorial function, great for novice producers navigating the settings for the first time.
Mounting Options
Control Your Way
Mount your PTZOptics Move 4K camera above, below, or beside the action to capture the ideal view every time.
The new automatic video inversion feature senses the camera's orientation and saves time on installation and setup.
Users can control Move 4K cameras using video production software such as OBS, Livestream Studio, Wirecast, vMix, mimoLive, or Tricaster, or a PTZOptics hardware joystick controller such as the IP joystick, serial joystick, or SuperJoy. The options for camera control are endless, allowing you to take charge of your camera in a way that fits your workflow.
Move 4K cameras can be controlled remotely from anywhere in the world using a variety of tools, including NDI and cloud-based software such as Zoom. Users can also live stream directly to content delivery networks such as Facebook and YouTube.
Software App
PTZOptics cameras are compatible with a wide range of free software solutions, including:
- Camera Management Platform (CMP) for camera management, control, color correction, auto-tracking
- Control apps for desktop and mobile devices
- Plugins and integrations for popular platforms, including OBS and Twitch
- Camera configuration and management tools
- Support and testing utilities
In the Box
- PTZOptics Move 4K SDI/HDMI/USB/IP PTZ Camera with 30x Optical Zoom (Gray)
- IR Remote Control
- 12 VDC Power Adapter
- USB-A to USB-A Cable
- RS-232 Cable
- 2 x AA Battery
- Limited 5-Year Manufacturer Warranty
Guides & Manuals
Table of Contents
- Description
- Auto-Tracking PTZ Camera
- Multiple Output Options
- Pan, Tilt, Zoom, Track
- Mounting Options
- Control Your Way
- Software App
PTZOptics PT30X-4K Specs
Imaging
| Image Sensor | 1/1.8"-Type CMOS |
| Sensor Resolution | Effective: 8.42 Megapixel (3840 x 2160) |
| IR Cut Filter | No |
| Built-In ND Filter | None |
| Focus Control | Autofocus Manual Focus |
Exposure Control
| Shutter Type | Electronic Global Shutter |
| Shutter Speed | 1/10000 to 1/30 Second |
| Signal-to-Noise Ratio | 55 dB |
| Minimum Illumination | 0.5 Lux |
| Flip / Mirror Support | Image Flip, Mirror (Vertical) |
Lens
| Focal Length | 7.1 to 210mm (35mm Equivalent: 32 to 825mm) |
| Optical Zoom Ratio | 30x |
| Max Digital Zoom | 16x |
| Field of View | Horizontal: 59.2 to 2.5° Vertical: 34.6 to 1.4° |
| Maximum Aperture | f/1.61 to 5.19 |
Video Capture
| External Recording Modes | SDI/BNC HD (1920 x 1080p) at 25/29.97/50/59.94/60.00 fps HD (1920 x 1080i) at 50/59.94/60.00 fps HD (1280 x 720i) at 59.94/60.00 fps HDMI / RJ45 / USB UHD 4K (3840 x 2160) at 25/29.97/50/59.94/60.00 fps HD (1920 x 1080p) at 25/29.97/50/59.94/60.00 fps HD (1920 x 1080i) at 50/59.94/60.00 fps HD (1280 x 720i) at 59.94/60.00 fps |
| Broadcast Output | NTSC/PAL |
| IP Streaming | H.264, H.265, MJPEG, NDI|HX, RTMP, RTSP, SRT 640 x 360 to 3840 x 2160 to 320 x 240 to 720 x 480 to |
| IP Multi-Stream Support | Simultaneous H.264, H.265, MJPEG, RTMP, RTSP: 2160p, 1080p, 720p, 480p, 360p |
Control
| Presets | 255 |
| Move Speed | Pan: 1.7 to 100°/sec Tilt: 1.7 to 69.9°/sec |
| Movement Range | Tilt: 120° (-30 to 90°) |
| Tally Light | Yes |
| Supported Control Protocols | IP IR NDI Pelco-D Pelco-P RS-232 RS-485 VISCA |
Interface
| Video I/O | 1 x HDMI 2.0 Output 1 x BNC (3G-SDI) Output 1 x RJ45 (NDI) Output 1 x USB-A 2.0 Output |
| Audio I/O | 1 x 1/8" / 3.5 mm TRS Stereo Line Input 1 x 1/8" / 3.5 mm TRS Stereo Line Output |
| Other I/O | 1 x D-Sub 8-Pin (RS-232) Control Input 1 x D-Sub 8-Pin (RS-232) Control Output 1 x Block 2-Pin (RS-485) Control Input/Output |
| Built-In Speaker | No |
Power
| PoE Support | PoE+ 802.3at |
| Power I/O | 1 x DC (12VDC) Input |
| Power Consumption | Device: 12 VDC at 2 A (12 W) |
Environmental
| Operating Temperature | 14 to 104°F / -10 to 40°C |
| Storage Temperature | -40 to 140°F / -40 to 60°C |
General
| Material of Construction | Aluminum, Plastic |
| Dimensions (W x H x D) | 9 x 7.1 x 6.7" / 228 x 181 x 170 mm |
| Weight | 4.4 lb / 2 kg |
Packaging Info
| Package Weight | 8.21 lb |
| Box Dimensions (LxWxH) | 12.8 x 12.2 x 11.8" |
