Description
PTZCam UV510A Overview
- 1Description
- 2Applications
- 3High-Definition Image
- 4Leading Autofocus Technology
- 5Low Noise and High SNR
- 6Audio Input Interface
- 7Quiet and Quick Pan/Tilt Mechanism
- 8A/V Compression
- 9Multiple Network Protocol
- 10Serial Functions
- 11Low-Power Sleep Function
Add a camera to your conference room for remote meetings with software such as Skype, Microsoft Teams, or Zoom with this UV510A HDMI/3G-SDI/NDI PTZ Camera with 20x Optical Zoom from PTZCam. The PTZ camera features resolutions up to 1080p60, a 1/2.8" HD CMOS sensor, and an integrated 20x optical zoom lens to capture crisp imagery for your classroom, meeting room, or web conference. The camera offers multiple video output options including HDMI, 3G-SDI, RJ45 Ethernet RTSP streaming, and NDI|HX low-bandwidth, high-quality streaming.
In addition to HDMI and SDI output up to 1080p60, the camera will fit seamlessly into your NDI network and communicate with other NDI applications and hardware. You can set the camera to rapidly move between positions using IP RS-485, or RS-232 control with separately available controllers, and it also supports cascading over RS-232. The camera supports H.264 compression and it transmits IP video streams using ONVIF, RTSP, and RTMP protocols. The camera features a 3.5mm analog audio input and it supports AAC, MP3, and PCM audio compression and embedding over HDMI, 3G-SDI, and NDI|HX.
Applications
High-Definition Image
Leading Autofocus Technology
Low Noise and High SNR
Audio Input Interface
Quiet and Quick Pan/Tilt Mechanism
A/V Compression
Multiple Network Protocol
Serial Functions
Low-Power Sleep Function
In the Box
- PTZCam UV510A HDMI/3G-SDI/NDI|HX PTZ Camera with 20x Optical Zoom
- Limited 1-Year Warranty
- Description
- Applications
- High-Definition Image
- Leading Autofocus Technology
- Low Noise and High SNR
- Audio Input Interface
- Quiet and Quick Pan/Tilt Mechanism
- A/V Compression
- Multiple Network Protocol
- Serial Functions
- Low-Power Sleep Function
PTZCam UV510A Specs
| Image Sensor | 1-Chip 1/2.8" CMOS Sensor |
| Sensor Resolution | Effective: 2 Megapixel |
| Built-In Speaker | No |
| Built-In ND Filter | None |
| Flip / Mirror Support | Image Flip, Mirror (Vertical) |
| Optical Zoom Ratio | 20x |
| Focus Control | Autofocus Manual Focus |
| Output Formats | SDI, HDMI, RJ45: 1920 x 1080p at 30, 60 fps |
| Embedded Audio | HDMI: 2-Channel SDI: 2-Channel |
| IP Streaming | H.264, RTMP, RTSP: 1080p |
| Recording Modes | Not Specified by Manufacturer |
| Supported Control Protocols | IP RS-232 RS-485 VISCA |
| Video Output Connectors | 1 x BNC (3G-SDI) Female 1 x HDMI Type A Female 1 x RJ45 (HX / NDI) Female |
| Audio I/O | 1 x 1/8" / 3.5 mm Stereo Line Level Input |
| Control Interface | 1 x 8-Pin Mini-DIN (RS-232) Input 1 x 8-Pin Mini-DIN (RS-232) Output 1 x RJ45 (IP Control, LAN, VISCA) Input |
| Other I/O | 1 x 2-Pin Euroblock (RS-485) Input/Output |
| PoE Support | Yes |
| Power Connectors | 1 x Barrel / Coaxial (12 VDC) |
| Dimensions | 9.8 x 9.8 x 9.8" / 25 x 25 x 25 cm |
| Weight | 105.8 oz / 3 kg |
| Package Weight | 4.725 lb |
| Box Dimensions (LxWxH) | 10.6 x 10.1 x 9" |
PTZCam UV510A Reviews
Buyer Beware - Non-standard default IP
--NOTE TO FUTURE BUYERS-- A local network set with a 192.168.1.xxx IP range WILL NOT recognize these cameras at first. You must reconfigure your network, set a static IP (removing your dunamic IP settings) to set the new range to be 192.168.5.xxx and then access them. You can then go in and change the camera's default IP to a 192.168.1.xxx range to better match your network. This was a hassle, and the poor instructions for doing so in the manual, and lack of support form both and the PTZCam company was enough for me to return them and buy better cameras from a known company. I purchased these thinking this was a great deal hoping for a simple plug-and-play into my existing workflow... unfortunately this was not the case. I'm not a network administrator so I know there are things I don't know, but i'm also not entirely in the dark with networking so for me to have to alter my DNS settings on my LAN in order to configure these caused a bit of anxiety. Although I did return thesem I have since been told that the 192.168.5.xxx address is still considered a standard class c address, it was however, not on my radar as a step needed to set these devices up on my existing LAN. In order to access the cameras with the controller, NDI, or even a direct connect computer, you will have to access your network configurations and alter your Dynamic IP to a static IP and force a new subnet mask and default gateway. I have been reassured from that these have been tested and there is no malware or spyware, but altering an IP range for my network to give a camera access just screamed Red Flag to me so I did return them. Another red flag... the PTZCam brand is just a whitelable name given to these Minrray cameras of the same model number. This seemed to confuse a string of employees at that kept sending me to PTZOptics for help... This is NOT a PTZOptics camera, and the Minrray help support phone line is non-existant. I would seriously reconsider purchasing this brand/bundle before you find yourself in a similar situation as I have.
