Description
BZBGEAR BG-ADAMO-JR 20x Overview
Setup your conference room, office, or classroom for live streaming with this ADAMO HD 20x PTZ Camera Kit with Ceiling Mount and 33' USB 3.0 Cable from BZBGear. The kit includes one white ADAMO Jr HD 20x PTZ camera, a white ceiling mount, and a 33' long USB cable.
The ADAMO Jr camera supports video resolutions up to 1080p60 and it can output via HDMI, 3G-SDI, IP streaming, and USB 3.0. The included 33' USB 3.0 cable allows you to extend your camera's reach from a USB-enabled computer or switcher.
Capture high-resolution 1080p60 imagery in your conference room, event space, or house of worship with the white Live Streaming HD PTZ Camera with Auto-Tracking, Tally & 20x Zoom from BZBGear. This camera features a 1/2.8" 2.07MP CMOS sensor, a 20x optical zoom, accurate autofocus, subject auto-tracking, and simultaneous output via HDMI, 3G-SDI, USB 3.0, USB 2.0, and IP streaming with SRT support. You can embed analog audio into your video using the 3.5mm audio input.
You can record the camera's capture up to 1080p60 resolution onto an optional microSD card up to 1TB. The camera features LED tally lights to indicate the camera is on or idle. The camera supports PoE (Power-over-Ethernet), so it can be controlled, powered, and can stream over one connector, and it also supports RS-232 and RS-422 serial control.
Offered here in white, the Universal PTZ Camera Ceiling Mount from BZBGear is a slim-profile mount designed for mounting a PTZ camera to a ceiling. Multiple mounting points accommodate various mounting options, and the bracket's rubberized surface prevents unwanted movement. Constructed from heavy-gauge steel and featuring a powder coated finish, this bracket mounts directly to wood, drywall, and masonry. Camera mounting hardware and anchors are included.
Items Included
- BZBGEAR Live Streaming HD PTZ Camera with Auto-Tracking, Tally & 20x Zoom (White)
- IR Remote Control
- Power Adapter
- RS-232 Control Cable
- USB 2.0 Cable
- USB 3.0 Cable
-
Limited 3-Year Manufacturer Warranty
Registration Extension: 2-Year - BZBGEAR Universal PTZ Camera Ceiling Mount (White)
- Mounting Hardware
- Limited 5-Year Manufacturer Warranty
- USB 3.0 Extension Cable (33')
Additional Resources
Guides & Manuals
BZBGEAR BG-ADAMO-JR 20x Specs
| Image Sensor |
1/2.8"-Type CMOS
|
| Sensor Resolution |
Effective: 2.07 Megapixel
|
| Shutter Speed |
1/10000 to 1/25 Seconds
|
| Optical Zoom Ratio |
20x
|
| External Recording Modes |
SDI/BNC / HDMI
1920 x 1080p at 25/29.97/30.00/50/59.94/60.00 fps 1920 x 1080i at 50/59.94/60.00 fps 1280 x 720 at 50/59.94/60.00 fps USB 1920 x 1080p up to 30.00 fps 1280 x 720 up to 30.00 fps 1024 x 576 up to 30.00 fps 960 x 540 up to 30.00 fps 640 x 480p up to 30.00 fps 800 x 448 up to 30.00 fps 640 x 360 up to 30.00 fps 432 x 240 up to 30.00 fps 320 x 176 up to 30.00 fps |
| Broadcast Output |
NTSC
|
| IP Streaming |
H.264/MJPEG/H.265 via RTSP/RTMP/ONVIF
1920 x 1080 at 60p |
| Supported Control Protocols |
IP
IR Pelco-D Pelco-P RS-232 RS-422 RS-485 VISCA |
| PoE Support |
PoE 802.3af
|
| Mounting |
1x 1/4"-20 Female for Bracket
|
| Image Sensor |
1/2.8"-Type CMOS
|
| Sensor Resolution |
Effective: 2.07 Megapixel
|
| Focus Control |
Autofocus
Manual Focus |
| Shutter Speed |
1/10000 to 1/25 Seconds
|
| Signal-to-Noise Ratio |
50 dB
|
| Minimum Illumination |
0.5 Lux
|
| Flip / Mirror Support |
Image Flip, Mirror (Vertical)
|
| White Balance |
Presets: Auto, Color Temperature, Manual, One Push
|
| Focal Length |
5.05 to 91.49mm
|
| Optical Zoom Ratio |
20x
|
| Field of View |
Horizontal: 60.04 to 3.45°
Vertical: 35.31 to 1.97° |
| Maximum Aperture |
f/1.8 to 2.9
|
| External Recording Modes |
SDI/BNC / HDMI
1920 x 1080p at 25/29.97/30.00/50/59.94/60.00 fps 1920 x 1080i at 50/59.94/60.00 fps 1280 x 720 at 50/59.94/60.00 fps USB 1920 x 1080p up to 30.00 fps 1280 x 720 up to 30.00 fps 1024 x 576 up to 30.00 fps 960 x 540 up to 30.00 fps 640 x 480p up to 30.00 fps 800 x 448 up to 30.00 fps 640 x 360 up to 30.00 fps 432 x 240 up to 30.00 fps 320 x 176 up to 30.00 fps |
| Embedded Audio |
HDMI/LAN (RJ45)/SDI/USB
|
| Broadcast Output |
NTSC
|
| IP Streaming |
H.264/MJPEG/H.265 via RTSP/RTMP/ONVIF
1920 x 1080 at 60p |
| Presets |
255 via IP, RS-232, VISCA
10 via IR |
| Pan/Tilt |
Pan: 340° (-170 to 170°) at 1.4 to 100°/s
Tilt: 120° (-30 to 90°) at 2.9 to 30°/s |
| Tally Light |
Yes
|
| Supported Control Protocols |
IP
IR Pelco-D Pelco-P RS-232 RS-422 RS-485 VISCA |
| Media/Memory Card Slot |
Single Slot: microSDXC Only
|
| Video I/O |
1x USB-B 3.0 / 3.1/3.2 Gen 1 Output
1x USB-A 2.0 Output 1x HDMI (Unspecified Signal) Output 1x BNC (12G-SDI) Output 1x RJ45 (Unspecified Signal) Output |
| Audio I/O |
1x 1/8" / 3.5 mm TRS Stereo Line Input
|
| Other I/O |
1x Block (RS-422, RS-485) Control Input
|
| Built-In Microphone |
No
|
| Built-In Speaker |
No
|
| PoE Support |
PoE 802.3af
|
| Power I/O |
1x Barrel (12VDC at 1.5 A) Input
|
| Power Consumption |
Power Supply: 110 to 220 VAC at 1.5 A (12 W)
|
| Operating Conditions |
14 to 122°F / -10 to 50°C at 20 to 80% Humidity
|
| Storage Conditions |
14 to 140°F / -10 to 60°C at 20 to 95% Humidity
|
| Impact Resistance |
No
|
| Environmental Resistance |
No
|
| Mounting |
1x 1/4"-20 Female for Bracket
|
| OS Compatibility |
Computer: Windows / macOS 11 or Later
Mobile: iOS Only |
| Weight |
4 lb / 1.8 kg (Body Only)
|
| Package Weight |
5.945 lb
|
| Box Dimensions (LxWxH) |
11.7 x 10.7 x 7.7"
|
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.
