Tilta 75mm Cine Fluid Head with 3-Stage Carbon Fiber Tripod Legs (17.6 lb Load, Space Gray)

Utilize a tripod system that stands up to the demands of ENG and EFP production with the space gray 75mm Cine Fluid Head with 3-Stage Carbon Fiber Tripod System from Tilta. The system features a 75mm three-stage carbon fiber tripod and an aluminum 75mm fluid head, and it supports 2.2 to 17.5 lb payloads. The head provides smooth movements with a 6-step dynamic counterbalance and four levels of pan/tilt drag, and it offers a smooth 8-step counterbalance and 4-step pan/tilt fluid drag.

The three-stage tripod boasts a broad working height range of 5.1 to 70.8" and is equipped with three stages of locking buckles, making it easy to set up and adjust the legs for different terrain. There are 1/4"-20 and 3/8"-16 threads on the tripod legs for attaching additional accessories, such as an extension arm or smartphone mount.

The head features a 75mm half ball base and four levels of adjustable drag, ensuring comfortable operation for a range of different systems. Smooth damping ensures fluid pitch and horizontal movement, easily creating a cinematic feel.

The tripod head supports between 2.2 and 17.5 lb, and the counterbalance has eight levels of dynamic balance adjustment, supporting perfect balance for systems within the weight requirement.

Compatible with DJI-Standard Arca-type quick release plates, eliminating the need for replacing quick release plates when transitioning to gimbals, greatly improving efficiency.

The carbon fiber legs are constructed with a unique carbon fiber-reinforced wrap and have a diameter of 36mm. On their own, they can support up to 110 lb, which is stronger than traditional carbon fiber processes.

This kit uses 3-stage telescoping legs that can adjust to different heights with three stages of locking buckles. This allows users to make individual leg height adjustments to accommodate different terrain and balance. The legs can extend between 5.1 and 70.8" in height.

Tilta TT-CT08-75 Specs

Head Type	Fluid Head
Drag Control	Yes
Primary Material	Carbon Fiber
Load Capacity	17.5 lb / 7.9 kg
Maximum Working Height	70.8" / 179.8 cm
Minimum Working Height	5.1" / 13 cm
Closed Length	Not Specified by Manufacturer
Weight	9.9 lb / 4.5 kg

Head Type	Fluid Head
Base Mount	75 mm Half Ball
Counter Balance	Incremental 8-Step
Dimensions	Base Diameter: 3.0" / 75.00 mm

Drag Control	Yes
Independent Pan Lock	Yes
Independent Tilt Lock	Yes
Vertical Tilt	+90° to -60°
Lateral Tilt	No

Primary Material	Carbon Fiber
Leg Lock	Flip Lock
Leg Sections	4
Independent Leg Spread	Yes

Load Capacity	17.5 lb / 7.9 kg
Maximum Working Height	70.8" / 179.8 cm
Minimum Working Height	5.1" / 13 cm
Closed Length	Not Specified by Manufacturer
Accessory Mounting	1x 1/4"-20 Female Thread 1x 3/8"-16 Female Thread
Bubble Level	Yes
Spreader Support	No
Weight	9.9 lb / 4.5 kg

Package Weight	15.31 lb
Box Dimensions (LxWxH)	31 x 8 x 7.8"
