Description
This is a 40 Watt 2:1 Input Range Dual Output DC/DC Converter, Input 18V to 36V, Output ± 15V/1.4A product from XP POWER with the model number JCP4024D15
Product details
| No. of Outputs | 2 Output |
| Output Power Max | 40W |
| Output Voltage - Output 1 | 15V |
| Output Current - Output 1 | 1.4A |
| Output Voltage - Output 2 | -15V |
| Output Current - Output 2 | 1.4A |
| Output Voltage - Output 3 | - |
| Output Current - Output 3 | - |
| Product Range | - |
| Input Voltage DC Min | 18V |
| Input Voltage DC Max | 36V |
| DC / DC Converter Output Type | Fixed |
| DC / DC Converter Type | DIP |
| DC / DC Converter Mounting | Through Hole |
| Approvals & Standards | - |
| Width | 50.8mm |
| Height | 10.2mm |
| Depth | 50.8mm |
Other details
| Brand | XP POWER |
| Part Number | JCP4024D15 |
| Quantity | Each |
| Technical Data Sheet EN |  |
