| ₹ 1620.0 includes GST and import duties. | |
| B2B customers can avail ₹ 247.05 ITC on this product | |
| 100% Secure Payments | 100% Genuine product |
Description
Product Overview
IL2424SH is an IL series unregulated, single output DC to DC converter in a SIP4 PCB mount package.
- 24VDC input voltage, 24V output voltage
- 84mA output current, 84% efficiency
- MTBF <gt/>1.2 MHrs, 3 year warranty
- 3000VDC isolation
- Variable switching frequency of 70KHz typical
- Non conductive black plastic (UL94V-0 rated) case material
- Operating temperature range from -40°C to +85°C
Product details
Other details
| Brand | XP POWER |
| Part Number | IL2424SH |
| Quantity | Each |
| Technical Data Sheet EN |  |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.
Bulk Discount
| Quantity | Price |
| 2 | ₹ 1587.6 |
| 3-5 | ₹ 1571.4 |
| 5-10 | ₹ 1539.0 |
| 10+ | ₹ 1506.6 |
Bulk discount will be automatically applied during checkout based on quantity.
