The DTJ10 series of chassis mount DC to DC power supplies allows for easy and convenient integration into a variety of industrial and commercial applications. The DC to DC power solution is constructed using copper case featuring short circuit protection, input reverse polarity protection and soft start.
- Wide 4:1 input range
- EN55032 conducted class A with no external components
- Remote on/off and voltage trim function
- 3KVDC isolation
- Operating temperature range from -40°C to +105°C
- Full power to 80°C
- MTBF is greater than 4Mhrs
- Dimension is 3.00" x 1.24" x 0.77" (76.2mm x 31.4mm x 19.4mm)
Product details
| Power Supply Approvals |
ITE |
| No. of Outputs |
1 Output |
| Output Power Max |
15W |
| Output Voltage - Output 1 |
5V |
| Output Current - Output 1 |
3A |
| Output Voltage - Output 2 |
- |
| Output Current - Output 2 |
- |
| Output Voltage - Output 3 |
- |
| Output Current - Output 3 |
- |
| Product Range |
DTJ Series |
| Input Voltage DC Min |
9V |
| Input Voltage DC Max |
36V |
| DC / DC Converter Mounting |
Chassis |
| DC / DC Converter Output Type |
Fixed |
Other details
| Brand |
XP POWER |
| Part Number |
DTJ1524S05-D |
| Quantity |
Each |
| Technical Data Sheet EN |
 |
