Description
Product Overview
The THN 30-2412 is a high performance DC/DC Converter Module with highest power density. The device achieves 30W output power, it offers 18 to 36VDC input voltage range and 12VDC output voltage. It has wide 2:1 input voltage range and precisely regulated output voltages, even under no load conditions. Highest efficiency across load range makes this device very reliable and applicable in temperature ranges of up to 85°C. With a low input current at no load and remote ON/OFF control this converter is the ideal solution for battery-operated systems. This device is suitable for use in an industrial electronics and many applications where space on the PCB is critical.
- Shielded metal case with isolated base plate
- Overtemperature protection
- Ultra low no load input current
- Output voltage adjustable
- 1500VDC I/O isolation voltage
- 91% Typical efficiency
- 24VDC Nominal input voltage
Applications
Consumer Electronics, Sensing & Instrumentation, Communications & Networking, Power Management
Product details
Other details
| Brand | TRACO POWER |
| Part Number | THN 30-2412 |
| Quantity | Each |
| Technical Data Sheet EN |  |
