Description
Product Overview
THN 10-3611UIR is a THN 10UIR series 10W high-performance DC/DC converter. Due to its dedicated holdup capacitor connection, the THN 10UIR meets extended holdup-time requirements without the need for bulky input capacitors. The THN 10UIR is EN 50155 certified for rolling stock applications, EN 61373 certified for resistance against mechanical shock and vibration and EN 45545-2 certified for fire behaviour. The THN 10UIR also comes with IEC/EN/UL 62368-1 safety approvals for use in a wide range of demanding industrial applications.
- Compact 1�x1� housing
- Ultra-wide 12:1 input range from 9-75VDC
- Natural convection cooling without derating -40°C up to 80°C
- Fully encapsulated DC/DC railway converter
- 3000 VDC I/O isolation
- Remote on/off and trim function
- Protection against short-circuit, overvoltage and overtemperature
- 5.1VDC nominal voltage and 2000mA max current (output 1)
- PD 2 pollution degree and natural convection cooling system
- 3-year product warranty
Product details
Other details
| Brand | TRACO POWER |
| Part Number | THN 10-3611UIR |
| Quantity | Each |
| Technical Data Sheet EN |  |
