Description
The TEP 75-2415WI is a 1-output DC to DC Converter with ultra wide 4:1 input voltage ranges. The TEP-75WI series 75W isolated high performance DC/DC converter module is suitable for a wide range of applications, but the product is designed particularly also for industrial applications where often no PCB mounting is possible but the module has to be mounted on a chassis. Four threaded M3 inserts in the module makes chassis mount or attachment of a heatsink for optimal thermal management very simple. For easy connection there is also a unique adaptor available with screw terminals. A very high efficiency allows an operating temperature up to +60°C with natural convection cooling without power derating. The very wide input voltage range and reverse input voltage protection make this converter also an interesting solution for battery operated systems.
- Rugged, compact metal case
- EN 50155 approval for railway applications
- Output voltage trimming
- Remote on/off
- Under-voltage lockout
- Reverse input voltage protection
- Input protection filter
Power Management, Industrial
Other details
| Brand | TRACO POWER |
| Part Number | TEP 75-2415WI |
| Quantity | Each |
| Technical Data Sheet EN |  |
| CAD Multiple Formats EN | |
| Miscellaneous EN | |
| Application Note EN | |
