| ₹ 1075.65 includes GST and import duties. | |
| B2B customers can avail ₹ 164.04 ITC on this product | |
| 100% Secure Payments | 100% Genuine product |
Description
This is a Non Isolated POL DC/DC Converter, Switching, 1 Output, 1.65 W, 3.3 V, 500 mA, Fixed, Through Hole product from RECOM POWER with the model number R-783.3-0.5
Product details
| No. of Outputs | 1 Output |
| Output Power Max | 1.65W |
| Output Voltage Nom. | 3.3V |
| Output Current Max | 500mA |
| DC / DC Converter Output Type | Fixed |
| DC / DC Converter Mounting | Through Hole |
| Input Voltage DC Min | 4.75V |
| Input Voltage DC Max | 32V |
| DC / DC Converter Type | SIP |
| Approvals & Standards | UL |
| Depth | 11.5mm |
| Width | 7.55mm |
| Height | 10.2mm |
| Product Range | R-78-0.5 Series |
Other details
| Brand | RECOM POWER |
| Part Number | R-783.3-0.5 |
| Quantity | Each |
| Technical Data Sheet EN |  |
| 3D Product Image EN | |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
Bulk Discount
| Quantity | Price |
| 2 | ₹ 1054.14 |
| 3-5 | ₹ 1043.38 |
| 5-10 | ₹ 1021.87 |
| 10+ | ₹ 1000.35 |
Bulk discount will be automatically applied during checkout based on quantity.
