MURATA POWER SOLUTIONS NMK1212SC Isolated Board Mount DC/DC Converter, 3kV Isolation, 2 Output, 2 W, 12 V, 83 mA, -12 V, 83 mA

This is a Isolated Board Mount DC/DC Converter, 3kV Isolation, 2 Output, 2 W, 12 V, 83 mA, -12 V, 83 mA product from MURATA POWER SOLUTIONS with the model number NMK1212SC

Product details

No. of Outputs	2 Output
Output Power Max	2W
Output Voltage - Output 1	12V
Output Current - Output 1	83mA
Output Voltage - Output 2	-12V
Output Current - Output 2	83mA
Output Voltage - Output 3	-
Output Current - Output 3	-
Product Range	muRata Ps NMK Series
Input Voltage DC Min	10.8V
Input Voltage DC Max	13.2V
DC / DC Converter Output Type	Fixed
DC / DC Converter Type	SIP
DC / DC Converter Mounting	Through Hole
Approvals & Standards	-
Width	7.65mm
Height	10.15mm
Depth	19.65mm

Other details

Brand	MURATA POWER SOLUTIONS
Part Number	NMK1212SC
Quantity	Each
Technical Data Sheet EN
3D Product Image EN
Product Change Notice EN
