Description
Product Overview
TEPS45F24 is a TEPS series PCB mount type, AC/DC power supply. Standard approvals are UL62368-1, C-UL (equivalent to CAN/CSA-C22.2 No.62368-1), EN62368-1. It complies with DEN-AN.
- Small and lightweight, high efficiency, ClassII
- Harmonic attenuator (complies with IEC61000-3-2), universal input
- Built-in inrush current, overcurrent and overvoltage protection circuits
- Universal input voltage range from 85 to 264VAC, 45.6W max output wattage
- 24VDC output voltage, 1.9A output current
- 91.5% (110V)/92.5% (230V) typical efficiency, 96mV max drift
- 3,000VAC isolation (input-output, 1min, 10mA, 500VDC)
- 5-year warranty
- Operating temperature range from -10 to 70°C
- Case size (W x H x D) is 25.4 x 24.0 x 58.5mm
Product details
Other details
| Brand | COSEL |
| Part Number | TEPS45F24 |
| Quantity | Each |
| Technical Data Sheet EN |  |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.
Bulk Discount
| Quantity | Price |
| 2 | ₹ 9811.29 |
| 3-5 | ₹ 9711.17 |
| 5-10 | ₹ 9510.94 |
| 10+ | ₹ 9310.71 |
Bulk discount will be automatically applied during checkout based on quantity.
