| ₹ 15265.28 includes GST and import duties. | |
| B2B customers can avail ₹ 2327.96 ITC on this product | |
| 100% Secure Payments | 100% Genuine product | |
| The product is eligible for Free Shipping |
Description
Product Overview
KHEA90F-24 is a KH series DIN rail type, AC-DC power supply. Safety agency approvals are UL60950-1, C-UL (CSA60950-1), EN62368-1, UL508, NEC Class2 (24V output only option -E), UL121201, ATEX, complies with DEN-AN (AC input), UL60950-1, C-UL (CSA60950-1), EN62368-1 (DC input).
- Euro style I/O terminals
- Wide operating ambient temperature range
- Built in overcurrent protection, overvoltage protection circuits
- Low power consumption at no load, complies with SEMI F-47
- Input voltage range from 85 to 264VAC/88 to 250VDC
- 91.2W max output wattage, 24VDC output voltage, 3.8A output current
- 87% (ACIN 115V)/88% (230V) typical efficiency
- 3,000VAC isolation (1minute, input-output, 10mA, 50Mohm min)
- 5-year warranty, operating temperature range from -20 to +70°C
- Case size (W x H x D) is 50 x 90 x 90mm
Product details
Other details
| Brand | COSEL |
| Part Number | KHEA90F-24 |
| Quantity | Each |
| Technical Data Sheet EN |  |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.
Bulk Discount
| Quantity | Price |
| 2 | ₹ 14959.97 |
| 3-5 | ₹ 14807.32 |
| 5-10 | ₹ 14502.02 |
| 10+ | ₹ 14196.71 |
Bulk discount will be automatically applied during checkout based on quantity.
