BLOCK PM-0112-040-0 AC/DC DIN Rail Power Supply (PSU), ITE, 1 Output, 48 W, 12 VDC, 4 A

PM-0112-040-0 is a PM 1AC series primary switched mode power supply. The efficient, primary switched mode power supply in slim plastic enclosure. A powerful and flexible option that's still light and compact. It is suitable for a highly diverse range of applications in solar, measurement and control technology as well as industrial and building automation. All power supplies also comply with the EN 60335-1 standard for domestic appliances. The output voltage can be easily set using the rotary potentiometer on the front of the enclosure. The DIN rail fastening method and push-in connection terminals enable fast and secure mounting. Safety standards are EN 61558-2-16, EN 60950-1, EN 60335-1, EN 61204-3.

• DC OK signalling, constant current limiting without overload shutdown
• Input rated voltage is 100 - 240VAC, rated frequency range from 44Hz - 66Hz /0Hz
• Output rated voltage is 12VDC, output rated current is 4A / NEC Class 2
• Protection index is IP20
• Power dissipation, no load/rated load is <lt/>1W / 8W (230VAC), efficiency is 86%
• Stabilised and adjustable output voltage, low stand-by consumption <lt/>1W, push-in terminals
• 3 years warranty, in compliance with EN 60335-1, panel installation on mounting rails
• UL/CSA 60950 recognised, UL 508 listed, GL approved
• Ambient temperature range from -25°C to +70°C
• Dimension is 45mm width x 90mm height x 98mm depth
