- Step-up converter with output disconnect and battery detection feature in 8 pin TSOT-23 package
- 9.5µA low quiescent current
- Less than 650nA shutdown current
- Up to 80% efficiency at 100µA to 200µA light Load condition
- Output disconnect in shutdown
- Down mode when VIN> VOUT
- Adjustable low battery detection, internal synchronous rectifier
- Overtemperature protection with thermal shutdown at 155°C
Footnotes MPS part numbers ending in "-P" and "-Z" are the same parts. P & Z only indicates reel size. Warnings Market demand for this product has caused an extension in leadtimes. Delivery dates may fluctuate. Product exempt from discounts.
Other details
| Brand |
MONOLITHIC POWER SYSTEMS (MPS) |
| Part Number |
MP3416GJ-P |
| Quantity |
Each (Supplied on Cut Tape) |
| Technical Data Sheet EN |
 |
