- Single Output
- SIP Package
- 1000 VDC Isolation
- Small Package Sizes
- -40°C to +85°C Operation
Product details
| Output Power Max |
250mW |
| Input Voltage DC Min |
4.5V |
| DC / DC Converter Mounting |
Through Hole |
| Output Voltage - Output 2 |
- |
| Output Current - Output 2 |
- |
| Depth |
11.68mm |
| Width |
6.1mm |
| Product Range |
IK Series |
| DC / DC Converter Type |
SIP |
| Approvals & Standards |
- |
| Output Voltage - Output 3 |
- |
| Output Voltage - Output 1 |
12V |
| Output Current - Output 3 |
- |
| No. of Outputs |
1 Output |
| DC / DC Converter Output Type |
Fixed |
| Input Voltage DC Max |
5.5V |
| Output Current - Output 1 |
20.83mA |
| Height |
9.8mm |
Other details
| Brand |
XP POWER |
| Part Number |
IK0512SA |
| Quantity |
Each |
| Technical Data Sheet EN |
 |
