INFINEON TLE7230RAUMA1 Power Load Switch, Smart Power Technology, Low Side, 8 Outputs, 2A, SOIC-36 TLE7230R, SP000311685

TLE7230RAUMA1 is a smart octal low-side switch in smart power technology (SPT) with a serial peripheral interface (SPI) and eight open drain DMOS output stages. It is protected by embedded protection functions and designed for automotive and industrial applications. The output stages are controlled via an SPI Interface. Additionally, four channels can be controlled in parallel for PWM applications. This feature makes the TLE 7230 R particularly suitable for engine management and body systems. Application includes µC-compatible 8-channel low-side switch, switch for automotive and industrial applications, solenoids, relays and resistive loads.

• Overload, short circuit, overtemperature, overvoltage protection
• 10µA minimum supply current (reset mode, Reset = L, Tj = - 40°C to + 150°C)
• 16bit SPI (for daisy \chain)m direct parallel control of four channels
• PWM input (demux), parallel Inputs high or low active programmable
• Programmable functions, boolean operation, overload behaviour
• Overload behaviour, overtemperature behaviour, switching time
• General fault flag, digital ports compatible to 5V and 3.3V microcontrollers
• Electrostatic discharge (ESD) protection
• Full reverse current capability without latch up
• SO 36 package, operating temperature range from -40 to +150°C
