Description
Middle Atlantic RLNK-920R Overview
Monitor your power and control it remotely with the RLNK-920R 9 Outlet Select Series Power Distribution Unit with RackLink from Middle Atlantic. The RLNK-920R provides nine, controllable, rear-mounted outlets, and one convenient front-access outlet with basic surge protection on all outlets. Connect to your network via Ethernet for IP control, monitoring, and scheduling. Using the RackLink Discover app on iPhone or Android you can monitor and control your RackLink units from anywhere, anytime.
IP Network Control
The RLNK-920R gives you the control you need to maintain the uptime of your equipment. After you go through the easy setup of the RackLink user interface, you'll have individual IP outlet control for four outlets.
Moblie App for iPhone and Android
Using the RackLink Discovery app on iPhone or Android, quickly connect your RackLink enabled PDUs and monitor your system, anywhere, anytime. Improve your system reliability by automating actions such as multiple IP AutoPing and recovery. You can also receive automatic notifications of connection status.
Protect Your Equipment
Each PDU comes with basic surge protection to prevent spikes and overloads to protect your devices from harmful power anomalies.
Third-Party Control
The RLNK-920R seamlessly interfaces with third-party AV control systems and cloud platforms for scheduling, control, reporting, and even customization.
UPC: 656747395505
Items Included
- Middle Atlantic RLNK-920R 9 Outlet Select Series Power Distribution Unit with RackLink
- Power Cord
- Limited 3-Year Manufacturer Warranty
Additional Resources
No additional resources available
Middle Atlantic RLNK-920R Specs
Key Specs
| Metering |
None
|
| Battery Backup |
No
|
| Outlets |
1x NEMA 5-20R (Front Panel)
8x NEMA 5-20R (Rear Panel) |
| Additional I/O |
1x RJ45
|
| Surge Protection |
Yes: 120 Joules
|
| Type |
Distributor
|
| Amp Rating |
16 A
|
| Number of Circuits |
1
|
| Metering |
None
|
| Battery Backup |
No
|
| Typical Backup Runtime |
Not Specified by Manufacturer
|
| Integrated Lamps |
No
|
Connections
| Outlets |
1x NEMA 5-20R (Front Panel)
8x NEMA 5-20R (Rear Panel) |
| Wall Plug Type |
NEMA 5-20P (Straight)
|
| AC Power I/O |
1x IEC Input (Locking)
|
| Lamp I/O |
No
|
| Additional I/O |
1x RJ45
|
| Wireless |
Bluetooth
|
Electrical
| AC Input Power |
120 VAC, 60 Hz (12 A)
|
| DC Output Power |
Not Specified by Manufacturer
|
| Output Current |
20 A (Maximum)
|
| Load Capacity |
Not Specified by Manufacturer
|
| Sequencing Delay |
Adjustable
|
Protection & Conditioning
| Protection Types & Modes |
Line to Neutral, Zero Ground Leakage
|
| Circuit Breaker |
Yes
|
| Clamping Response Time |
< 1 ns
|
| Maximum Spike Current |
15 A
|
| Surge Protection |
Yes: 120 Joules
|
Physical
| Rackmount Size |
1 U
|
| Cable Length |
9' / 2.7 m
|
| Certifications |
CSA C22.2 No. 62368-1, FCC Part 15, Class B, UL 62368-1, cETLus
|
| Operating Conditions |
32 to 104?F / 0 to 40?C up to 95% Humidity
|
| Cable Management |
No
|
| Dimensions |
19 x 9.7 x 1.7" / 482.6 x 245.7 x 44.1 mm
|
