Description
Anchor Audio Bigfoot 3 Overview
Designed to deliver versatile and powerful amplification to crowds of up to 2500 people, the Anchor Audio Bigfoot 3 with AnchorFlex is a portable line-array PA system that's built to dominate crowds while amplifying to anywhere with deeper bass, seamless connectivity, and limitless flexibility. With a 150 x 150' coverage area, the Bigfoot 3 is well suited for sports venues, educational facilities, and various indoor and outdoor events. The 300W amplifier drives five 8" neodymium woofers and a single neodymium compression driver, which combine to provide a 100 Hz to 15 kHz frequency response and a maximum 130 dB SPL, plenty of volume to cover your audience. AnchorFlex is the highly flexible, battery-powered broadcast audio transceiver with a range of up to 300'.
The built-in Bluetooth receiver allows streaming of music from your smartphone, tablet, or laptop. Two combo XLR-1/4" inputs accommodate wired microphones, while a 1/4" TS input accepts line level and Hi-Z inputs. A 3.5mm input is also available for connecting your favorite portable devices. The balanced 1/4" output can be routed to another PA system or an audio recorder. The integrated mixer functions include volume controls and a 2-band equalizer. Power the via AC power or the three 12V lithium iron phosphate (LiFePo4) rechargeable batteries, which offer a playback time of 7" hours and a 5 hour recharge time. The large, oversized wheels ensure easy transport across fields and gymnasiums.
- Three built-in rechargeable lithium-ion batteries (7+ hours of playtime)
- Class 1 Bluetooth with 150' range, so you can stream audio right to your speaker
- Line array components that include five 8? neodymium woofers, and one neodymium compression driver
- Two balanced XLR-1/4" combo inputs for wired microphones, one 1/4" unbalanced Line In for mixers and instruments, one 1/4" line out for connecting companion speakers
- Folding design that's easy to set up with just one person
- Rugged, weatherproof case designed to keep your electronics safe when you play or transport your speaker
- Heavy-duty wheels designed to go everywhere
- Switch speakers from transmitting to receiving mode on the go
- Switch between mono and stereo with the push of a button
- Use only one transmitting speaker to feed 1 stereo connection or up 1000 receiving speakers mono speaker, all with crystal-clear sound
- AnchorFlex is available on Series 3 Connect models
Items Included
- Anchor Audio Bigfoot 3 Portable Line Array PA System with Bluetooth and AnchorFlex Transceiver
- Power / Charging Cable
- Limited 6-Year Manufacturer Warranty (Line Array)
- Limited 4-Year Manufacturer Warranty (Battery)
Additional Resources
No additional resources available
Anchor Audio Bigfoot 3 Specs
| Speaker Configuration |
1x 2-Way Loudspeaker
|
| Number of Input Channels |
3 (3 x Mono, 1 x Stereo)
|
| Amplifier Power Rating |
300 W
|
| HF Driver |
1x Compression Driver
|
| LF Driver |
5x 8" / 20.3 cm Woofer
|
| Audio I/O |
2x Combo XLR-1/4" 3-Pin Female Balanced Mic Input
1x 1/4" TS Female Unbalanced Line/Hi-Z Input 1x 1/8" / 3.5 mm TRS Female Unbalanced Line Input 1x 1/4" TS Female Unbalanced Line Output 1x speakON NL4 Speaker Output |
| Bluetooth |
Yes
|
| Speaker Configuration |
1x 2-Way Loudspeaker
|
| Number of Input Channels |
3 (3 x Mono, 1 x Stereo)
|
| Amplifier Power Rating |
300 W
|
| Enclosure Type |
Bass-Reflex
|
| HF Driver |
1x Compression Driver
|
| LF Driver |
5x 8" / 20.3 cm Woofer
|
| Magnet |
HF Driver/LF Driver:
Neodymium |
| EQ |
1x HF Shelf
1x LF Shelf |
| Semi-Parametric EQ |
No
|
| Effects |
No
|
| Filters |
No
|
| Dynamic Processing |
No
|
| Frequency Response |
100 Hz to 15 kHz
|
| Maximum SPL |
130 dB
|
| Max Coverage Distance |
150' / 45.7 m
|
| Max Coverage Area |
150 ft? / 45.7 m?
|
| I/O Impedance |
Combo XLR-1/4" Mic Input:
10 Kilohms 1/4" Line Output: 600 Ohms |
| Audio I/O |
2x Combo XLR-1/4" 3-Pin Female Balanced Mic Input
1x 1/4" TS Female Unbalanced Line/Hi-Z Input 1x 1/8" / 3.5 mm TRS Female Unbalanced Line Input 1x 1/4" TS Female Unbalanced Line Output 1x speakON NL4 Speaker Output |
| Phantom Power |
+34 V
|
| Mobile App Compatible |
No
|
| Network I/O |
No
|
| Wireless Connectivity |
Bluetooth, RF Transmitter
|
| Max Wireless Range |
Bluetooth:
150' / 45.7 m Speaker Link: 300' / 91.4 m |
| Bluetooth |
Yes
|
| Battery Type |
3x Rechargeable 12 V Lithium (Replaceable)
|
| Approximate Battery Life |
7 Hours
|
| Battery Charging Time |
5 Hours
|
| Internal Battery Capacity |
7.5 Ah
|
| AC Input Power |
100 to 240 VAC, 50 / 60 Hz
|
| Current Consumption |
3.5 A
|
| AC Power I/O |
1x IEC 2-Pin
|
| Transport Options |
1x Handle (Top)
2x Wheels (Bottom) |
| Dimensions |
68.5 x 23 x 14" / 174 x 58.4 x 35.6 cm (Full Assembly)
42.5 x 23 x 14" / 108 x 58.4 x 35.6 cm (Collapsed) |
| Weight |
64 lb / 29 kg
|
| Package Weight |
75 lb
|
| Box Dimensions (LxWxH) |
43 x 25 x 16"
|
