Description
Product Overview
The MCV 1,5/ 2-G-5,08 from Phoenix Contact is a 5.08mm pitch, 2 pole header. The header has a plug-in direction vertical to the PCB.
- Nominal current is 8A
- Rated voltage (III/3) is 250V, (III/2) is 320V, (II/2) is 400V
- Rated surge voltage (III/3) is 4KV, (III/2) is 4KV, (II/2) is 4KV
- Green colour PBT insulating material, flammability rating according to UL94 V0
- Maximum flexibility design
- Contact surface is tin
- CSA, VDE, CCA, cULus, EAC standards
- Hole diameter is 1.2mm
- Pin dimension is 0.8mm x 0.8mm
- Vertical connection enables multi-row arrangement on the PCB
Applications
Industrial
Product details
| Gender | Header |
| No. of Positions | 2Ways |
| Rated Voltage | 300V |
| Product Range | MINI COMBICON |
| Pitch Spacing | 5.08mm |
| Rated Current | 8A |
| Block Orientation | Through Hole Vertical |
| SVHC | No SVHC (04-Feb-2026) |
Other details
| Brand | PHOENIX CONTACT |
| Part Number | 1836299 |
| Quantity | Each |
| Technical Data Sheet (116.03KB) EN | View or download |
