Description
Product Overview
The 231-332/001-000 is a 2-pole orange vertical PCB-mount Male Connector with straight solder pins. It is made with the tin-plated electrolytic copper (Ecu) contacts and polyamide 66 (PA 66) insulator. The male header features 1.2 x 1.2mm solder pins allow nominal current up to 16A, enhancing stability of shorter headers and the pin housing design prevents mismating.
- Enclosed on each side
- UL94V-0 Flammability rating
Applications
Industrial
Product details
| Gender | Header |
| No. of Positions | 2Ways |
| Rated Voltage | 300V |
| Product Range | MCS MIDI Classic 231 |
| Pitch Spacing | 5.08mm |
| Rated Current | 10A |
| Block Orientation | Through Hole Vertical |
| SVHC | No SVHC (04-Feb-2026) |
Other details
| Brand | WAGO |
| Part Number | 231-332/001-000 |
| Quantity | Each |
| Technical Data Sheet (152.13KB) EN | View or download |
| Drawing (1.11MB) EN | View or download |
