Description
Product Overview
The M20-1071000 is a 20-position double row SIL Crimp Housing made of black polyphenylene and polystyrene (PPE + PS). It can be used with M20-1160042, M20-1160046, M20-1180042 or M20-1180046 crimp contacts and mating male connectors.
- Suitable for wire sizes 22 to 30 AWG
- 3A AC/DC Current rating
- 250VAC Maximum voltage rating
- 20mΩ Contact resistance
- 5000MΩ Minimum insulation resistance
- 1500VAC for one minute Dielectric strength
- Operating temperature range -40°C to 105°C
- UL94 V-1 black colour polyphenylene and polystyrene (PPE + PS) material
- Mating Pin Length: 5.5mm to 6.3mm
Applications
Commercial, Industrial
Notes
Crimp contacts to be ordered separately
Product details
| Product Range | M20 |
| No. of Positions | 20Ways |
| For Use With | M20 Series Crimp Contacts |
| Gender | Receptacle |
| Pitch Spacing | 2.54mm |
| SVHC | No SVHC (04-Feb-2026) |
Other details
| Brand | HARWIN |
| Part Number | M20-1071000 |
| Quantity | Each |
| 3D Product Image (51.42KB) EN | View or download |
| Technical Data Sheet (46.80KB) EN | View or download |
| Manufacturer Catalogue (353.44KB) EN | View or download |
