Description
Product Overview
The 280366 is a 16-way 2-row Receptacle Housing with thermoplastic body, 2.54mm pitch spacing and crimp termination. Inline contact layout. This receptacle housing is suitable for use with wire/cable.
- Black housing
- UL94V-1 Flammability rating
- Pitch size is 2.54mm
- Operating temperature range -40°C to 80°C
- Contact resistance of 15mohm
- Insulation resistance of 5000Mohm
- Thermoplastic housings are UL 94V-1 and UL 94V-0 rated
- Tin and gold plated contacts available
- Features 0.63mm posts with mating connector
- Rugged
Applications
Industrial
Warnings
Market demand for this product has caused an extension in leadtimes. Delivery dates may fluctuate. Product exempt from discounts.
Product details
| Product Range | AMPMODU IV/V |
| No. of Positions | 16Ways |
| For Use With | AMPMODU IV/V Series Contacts |
| Gender | Socket |
| Pitch Spacing | 2.54mm |
| SVHC | No SVHC (04-Feb-2026) |
Other details
| Brand | TE CONNECTIVITY - AMP |
| Part Number | 280366 |
| Quantity | Each |
| Product Change Notice (128.81KB) EN | View or download |
| Drawing (71.95KB) EN | View or download |
| Technical Data Sheet (74.01KB) EN | View or download |
