Wurth Elektronik 865080257014 865080257014 SMD Aluminium Electrolytic Capacitor Radial Can - 1000 µF 10 V 2000 Hours @ 105°C Polar

Wurth Electronics Aluminum Electrolytic Capacitors are available in various designs: V-Chip, SMD, Radial THT, and Snap-In with high capacitances and voltages which are also available as non-polar versions. These are provided for the standard application with 85°C and 1000 h. In Aluminum Electrolytic Capacitors the cathode consists of wet electrolytic whereas the anode is made of an aluminum foil. An AI203 oxidization layer on the anode foil operates as the dielectric. In comparison to Aluminum Polymer Capacitors the Aluminum Electrolytic Capacitors are offered up to higher capacitance values (up to 33000 µF) and higher voltage ranges (up to 450 VDC).

• Available in 6.3 V, 10 V, 16 V, 25 V, 35 V and 50 V
• Recommended soldering: Reflow
• Operating temperature: -55°C to +105°C
• Load life: 2000 h at +105°C
• Low impedance, especially for filtering applications
• Input and output capacitor for switched-mode power supply

Applications

Power Management, Power Supplies, Signal Processing, Instrumentation, Industrial

Warnings Market demand for this product has caused an extension in leadtimes. Delivery dates may fluctuate. Product exempt from discounts.

Other details

Brand	WURTH ELEKTRONIK
Part Number	865080257014
Quantity	Each (Supplied on Cut Tape)
Technical Data Sheet EN
Product Change Notice EN
