The MCPKNPA anti-surge wire wound fixed high-power resistors with excellent flame-retardant coating adheres to IEC 61000-4-5 standards for surge protection in electronics. Surge immunity up to 10KV. Typical applications include motor control applications, TV, monitors, test & measurement equipment, surge protection & voltage divider, power supply, power electronic control, dishwashers, dryers, washing machine and energy/ smart/ digital meter.
- Colour coating is "green"
- Excellent flame resistance
- Too low or too high ohmic value can be supplied on a case-to-case basis
- Special fusing wire-wound resistor can be supplied on a case-to-case basis
- Special anti-surge function items available (per IEC 61000-4-5)
Product details
| Resistance:
680ohm
|
| Product Range:
MCPKNPA
|
| Power Rating:
7W
|
| Resistance Tolerance:
± 5%
|
| Resistor Case / Package:
Axial Leaded
|
| Voltage Rating:
500V
|
| Resistor Technology:
Wirewound
|
| Temperature Coefficient:
± 300ppm/°C
|
| Resistor Type:
Anti-Surge
|
| Product Diameter:
8.5mm
|
| Product Length:
30mm
|
| Product Width:
-
|
| Operating Temperature Min:
-55°C
|
| Operating Temperature Max:
155°C
|
| Qualification:
-
|
Other details
| Brand |
MULTICOMP PRO |
| Part Number |
MCPKNPA7WJ0681B00 |
| Quantity |
Each |
| Technical Data Sheet EN |
 |
