Ubiquiti USW-PRO-48-POE Overview
Expand your business's network with the fully manageable second-generation UniFi Pro PoE 48-Port Gigabit Managed PoE Network Switch with SFP+ from Ubiquiti. Designed with Layer 3 protocol support, the passively cooled 48-port Gigabit switch features a total power budget of 600W across 40 32W PoE connectors and eight 64W PoE++ ports for power-intensive devices such as high-resolution network security cameras. This switch supports a 176 Gb/s (88 Gb/s non-blocking) switching capacity with a 130.94 Mpps forwarding rate. Four 10 Gb/s SFP+ ports are available for additional network expansion using compatible devices. Administrators may monitor and manage the switch with the 1.3" touchscreen display or access and configure it and connected devices using the UniFi Network Controller application.
- Operation mode (switching, mirroring, or aggregate) per port
- Network/VLAN configuration
- Jumbo frame and flow control services
- Network settings
- Storm control setting per port
- Spanning tree configuration
- 802.1X control and RADIUS VLAN
- Debug terminal option for command-line interface
- Connection speed and duplex mode
- TX/RX data rates
- Network/VLAN setting
Ubiquiti Networks Managed Specs
| Ports | 40 x 10/100/1000 Mb/s Gigabit Ethernet (RJ45) (Uplink) PoE+ 8 x 10/100/1000 Mb/s Gigabit Ethernet (RJ45) (Uplink) PoE+ (Type 2) 4 x 10Gb SFP+ (Uplink) |
| Layer Services Supported | Layer 2 Support, Layer 3 Support |
| Supported Protocols | Auto-MDIX/MDI Port Mirroring |
| Transmission Method | Store-and-Forward |
| Supported IEEE Standards | 802.3af, 802.3at, 802.3bt |
| Forwarding Rate | 65.47 Mpps |
| Switching Bandwidth | 44 Gb/s (Non-Blocking) |
| OS Compatibility | macOS 10 or Later Windows 7 or Later Linux |
| Power Draw | 60.00 W (Max) |
| DC Input Power | 11.5 to 52 VDC at 11.54 A |
| AC Input Power | 100 to 240 VAC, 50 / 60 Hz |
| PoE Power Budget | 600 W |
| PoE per Port | 32 to 64 W |
| Power Supply Type | Internal |
| Operating Temperature | 23 to 104°F / -5 to 40°C |
| Operating Humidity | 10 to 90% |
| Certifications | CE, FCC, IC, as per Manufacturer |
| Cooling System | Passive |
| Indicator Lights | Link/Activity, Link/Activity/Speed, PoE, System |
| Rack Form Factor | 1 RU |
| Dimensions | 17.42 x 11.24 x 1.72" / 442.4 x 285.4 x 43.7 mm |
| Weight | 9.48 lb / 4.3 kg |
