Description
Synology RX6025SAS Overview
The RX6025sas Expansion Unit from Synology provides high density storage expansion for their HD6500 servers. Built with a 4 RU form factor, it has 60 drive bays which support 3.5" SAS hard drives and 2.5" SATA SSDs through quick installation and intuitive setup in Synology DiskStation Manager (DSM). If you need even more storage, up to four RX6025sas units are supported. Connectivity to your HD6500 is established using one Mini-SAS HD (SFF-8644) port, while a second SFF-8644 port allows for connectivity to additional expansion units, so you'll be able to to tackle large-scale applications requiring cold or warm storage.
Please note that to install 2.5" SATA SSDs, 2.5" drive trays (R5) must be purchased separately.
Massive Storage Expansion
Accommodate growing storage demands by adding 60 additional drives to your HD6500 in minutes. Support for up to four expansion units enables seamless storage growth without costly disruptions. Support for SAS multipathing provides up to double the performance when deploying multiple expansion units, while online storage expansion and the comprehensive management tools in Synology DiskStation Manager (DSM) streamline setup and ongoing management.
Designed for Service Uptime
Tackle large-scale applications while maintaining the highest level of service availability thanks to clever hardware solutions.
SAS Multipathing
SAS multipathing maximizes resiliency against hardware malfunctions by providing alternate physical paths, allowing the system to reroute data when the primary interface or connection fails.
Redundant Components
Modular drive trays and system fans reduce the impact of maintenance on service availability, allowing for easy and quick replacement. Redundant power supply units provide continuous data availability even during power source failures.
Plug-and-Play Deployment
Minimize downtime when expanding your storage infrastructure with online storage expansion, which allows you to add new volumes or expand RAID volumes on the RX6025sas without affecting services on the HD6500.
Achieve Peak Performance with Synology Drives
Synology drives' finely tuned firmware ensures maximum integration with Synology hardware and software. Backed by a testing regimen that replicates heavy data center use, they deliver optimal performance and reliability even when tackling the most demanding applications.
UPC: 846504006427
Items Included
- Synology RX6025sas Expansion Unit
- RKS-03 Rail Kit
- Accessory Pack
- Mini-SAS HD Cable (78.7")
- Mini-SAS HD Cable (39.3")
- 2 x AC Power Cord
- Limited 5-Year Manufacturer Warranty (From Date of Purchase)
Additional Resources
Synology RX6025SAS Specs
General
| Number of Bays |
60x 2.5"/3.5" SAS-3, SATA III (Hot-Swap)
|
| Inputs/Outputs |
1x Mini SAS (SFF-8644) Input
1x Mini SAS (SFF-8644) Output |
| Media Card Slots |
No
|
| PCI Expansion |
No
|
Electrical
| Input Power |
200 to 240 VAC, 50 / 60 Hz
|
| Power Consumption |
811.8 W (Typical)
231 W (Standby) |
| PSU |
2 x 1300 W (Supports Redundancy)
|
Physical
| Operating Conditions |
32 to 95?F / 0 to 35?C at 5 to 95% Humidity
|
| Storage Conditions |
-5 to 140?F / -20 to 60?C at 5 to 95% Humidity
|
| Certifications |
BSMI Class A, CE Class A, EAC, FCC Class A, KC, RCM, RoHS, UKCA, UL, VCCI
|
| Cooling |
4x 80 mm Fans
|
| Noise Level |
61.7 dBA
|
| Cable Length |
78.7" / 200 cm
|
| Dimensions |
40.2 x 19 x 6.9" / 1020 x 482 x 176 mm
|
| Weight |
74.7 lb / 33.9 kg
|
Packaging Info
| Package Weight |
107.7 lb
|
| Box Dimensions (LxWxH) |
48.5 x 24 x 17.75"
|
