Description
Asustor AX7012R Overview
The Xpanstor 12R 12-Bay NAS Expansion Enclosure from ASUSTOR may be used to expand the capacity of your NAS and grow your workflow. It features twelve 3.5/2.5" drive bays that support both SAS III and SATA III drives and connects to your NAS using one of its mini-SAS HD (SFF-8644) ports. Three internal and hot-swappable 80mm fans help keep things running cool, while support for RAID 0, 1, 5, 6, and 10 offers performance, data redundancy, or a combination of both. For those who do not require a RAID, JBOD, and Single allow each drive to be utilized individually. Also featured are dual redundant 650W power supplies, a BMC (IPMI) RJ45 port, and a 2 RU form factor.
Expanding Storage Space
The Xpanstor 12R helps you expand your storage space while enhancing data management flexibility and efficiency. NAS devices serve as a centralized storage solution that offers convenient file sharing, remote access, and backup all in one. When attached to an ASUSTOR NAS, the Xpanstor 12R provides more drive bays for easy capacity expansion, making it especially suitable for enterprise environments that require extensive data storage and management.
Easily Configure Using Storage Manager
The Xpanstor 12R appears in ADM natively and drives appear within Storage Manager, which makes managing and configuring the attached expansion unit easy. Use Storage Manager to set up RAID configurations as well as utilize snapshot features to further enhance data security and reliability.
Dual Redundant Power Supplies and Hot-Swappable Fan Design
The Xpanstor 12R is equipped with two 650W redundant power supplies and three hot-swappable fans, which increases overall operational efficiency and fault tolerance. Both power supplies can automatically switch to the other in the event one fails, ensuring continuous operation and data security. The hot-swappable fan design allows for fan replacement without downtime, effectively reducing maintenance and upgrade costs.
UPC: 887372001701
Items Included
- Asustor Xpanstor 12R 12-Bay NAS Expansion Enclosure
- 2 x AC Power Cord
- Mini-SAS HD (SFF-8644) Cable
- Rail Kit
- 48 x Flat Head Screw
- Limited 5-Year Manufacturer Warranty
Additional Resources
Asustor AX7012R Specs
General
| Number of Bays |
12x 3.5" SAS-3, SATA III (Hot-Swap)
|
| Inputs/Outputs |
2x Mini SAS (SFF-8644) SAS-3 (12 Gb/s) Input
2x Mini SAS (SFF-8644) SAS-3 (12 Gb/s) |
| Media Card Slots |
No
|
| PCI Expansion |
No
|
Electrical
| Input Power |
100 to 240 VAC, 50 / 60 Hz
|
| PSU |
2 x 650 W
|
Physical
| Operating Conditions |
32 to 104°F / 0 to 40°C at 5 to 95% Humidity
|
| Certifications |
BIS, BSMI, C-Tick, CE, EAC, FCC, Kcc, UKCA, VCCI
|
| Cooling |
3x 80 mm Hot-Swappable Fans
|
| Dimensions |
25.5 x 17.2 x 3.5" / 647 x 437 x 89 mm
|
| Weight |
29.0 lb / 13.2 kg
|
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.
Bulk Discount
| Quantity | Price |
| 2 | ₹ 455523.6 |
| 3-5 | ₹ 450875.4 |
| 5-10 | ₹ 441579.0 |
| 10+ | ₹ 432282.6 |
Bulk discount will be automatically applied during checkout based on quantity.
