Description
Lilliput UQ23 Specs
Key Specs
| Display Size |
23.8" / 60.5 cm
|
| Native Resolution |
3840 x 2160
|
| Touchscreen |
No
|
| HDR Support |
Yes: Hybrid Log Gamma
|
| Video I/O |
4x BNC (12G-SDI) Input
Show More
4x BNC (12G-SDI) Loop Output 1x HDMI 2.1 Input 1x HDMI 2.1 Loop Output |
| Media/Memory Card Slot |
No
|
| Video Format |
HDMI/SDI
Show More
8K: 59.94/50/29.97/25/23.98 DCI 4K: 59.94/50/29.97/25/23.98 1080p: 59.94/50/29.97/25/23.98 1080i: 59.94/50 Fiber DCI 4K: 59.94/50/30/29.97/25/23.98 1080p: 59.94/50/29.97/25/23.98 1080PsF: 29.97/25/23.98 1080i: 59.94/50 720p: 59.94/50 |
| Battery |
1x Gold Mount on Included, Interchangeable Plate
|
| Power Consumption |
90 W (Maximum)
|
Display
| Panel Type |
LCD
|
| Display Size |
23.8" / 60.5 cm
|
| Native Resolution |
3840 x 2160
|
| Aspect Ratio |
16:9
|
| Viewing Angle |
Horizontal: 178?
Vertical: 178? |
| Touchscreen |
No
|
| Maximum Brightness |
1200 nits / cd/m2
|
| Contrast Ratio |
1000:1
|
| Color Support |
16.7 Million Colors
|
| HDR Support |
Yes: Hybrid Log Gamma
|
| Color Gamut |
100% DCI-P3
86% Adobe RGB |
| LUT Support |
Yes
|
| Image Controls |
Check Field, Color Temperature Selection, False Color, H/V Delay, Histogram, Image Freeze, Picture-in-Picture, Pixel-to-Pixel Zoom, Vectorscope, Waveform
|
Inputs/Outputs
| Video I/O |
4x BNC (12G-SDI) Input
4x BNC (12G-SDI) Loop Output 1x HDMI 2.1 Input 1x HDMI 2.1 Loop Output |
| Embedded Audio |
HDMI/SDI
|
| Audio I/O |
1x 1/8" / 3.5 mm Headphone Output
|
| Built-In Speaker |
Stereo
|
| Power I/O |
1x XLR 4-Pin (24 VDC) Input
|
| Other I/O |
1x USB-A
1x RJ45 (RS-422) Input 1x RJ45 (RS-422) Output 1x RJ45 (GPI) 1x RJ45 (LAN) |
| Expansion Slots |
1x SFP+ Slot
|
| Media/Memory Card Slot |
No
|
Wireless
| Wi-Fi |
No
|
| Bluetooth |
No
|
| Mobile App Compatible |
No
|
Format Support
| Video Format |
HDMI/SDI
8K: 59.94/50/29.97/25/23.98 DCI 4K: 59.94/50/29.97/25/23.98 1080p: 59.94/50/29.97/25/23.98 1080i: 59.94/50 Fiber DCI 4K: 59.94/50/30/29.97/25/23.98 1080p: 59.94/50/29.97/25/23.98 1080PsF: 29.97/25/23.98 1080i: 59.94/50 720p: 59.94/50 |
Power
| Input Power |
15 to 24 VDC
|
| Battery |
1x Gold Mount on Included, Interchangeable Plate
|
| Power Consumption |
90 W (Maximum)
|
Mounting
| VESA Mounting-Hole Pattern |
100 x 100 mm, 75 x 75 mm
|
| Tripod/Accessory Mounting |
1/4"-20 Female
3/8"-16 Female |
General
| Operating Conditions |
32 to 122?F / 0 to 50?C
|
| Storage Conditions |
-4 to 140?F / -20 to 60?C
|
| Dimensions |
22.7 x 14.8 x 2.1" / 576.6 x 375.5 x 53.5 mm
|
| Weight |
17.0 lb / 7.7 kg
|
Packaging Info
| Package Weight |
24.905 lb
|
| Box Dimensions (LxWxH) |
26.8 x 19.6 x 6.9"
|
Additional Resources
No additional resources available
