Description
Contemporary Research 5111-001 Overview
The third-generation ATSC-SDI 4i HDTV Tuner from Contemporary Research features H.264 tuning up to 1080p60, HDMI output scaling up to 1080p, and IPTV streaming via an Ethernet port. The commercial-grade ATSC-SDI 4i supports analog and digital MPEG-2/H.264 channels in ATSC, clear QAM, and NTSC formats.
In addition to wireless and wired IR commands, control choices include two-way RS-232, IP Telnet, and UDP options. A menu-driven display offers a simple setup, and an onboard web page enables configuration, control, and monitoring for remote locations. To switch between antenna and cable feeds, pair the ATSC-SDI 4i tuner with a separately available RF-AB switch.
The ATSC-SDI 4i HDTV Tuner is fully compatible with the control commands and operation of prior models, and it shares the same 1 RU rack height with two units fitting in one rack space.
Key Features
- Simultaneous 3G-SDI and HDMI 1.3 output
- Tunes analog and digital channels in ATSC, clear QAM, and NTSC formats
- Supports MPEG2 and H.264 channels up to 1080p60
- Passes through IPTV stream from received digital channel
- Coaxial and optical SPDIF digital audio outputs
- AC-3, PCM, or variable PCM audio for SDI, HDMI, and digital audio ports
- Two-way RS-232, IP Telnet, and UDP control
- Daisy-chainable RS-232 control for up to nine tuners
- 608/708 closed captioning pass-through
In the Box
- Contemporary Research ATSC-SDI 4i HDTV Tuner with SDI & HDMI Outputs & IP Streaming
- PS12-1.5 Power Supply
- Contemporary Research Single Rack Kit
- Limited 2-Year Warranty
Contemporary Research 5111-001 Specs
| Tuning Modes | Air/Cable Input: 1 x F-Type (Female), 75-Ohm Impedance, -10 to 25 dBmV Typical Off-Air 2-69 (NTSC & 8-VSB) CATV 1-135 (64QAM, 256QAM, 8-VSB, NTSC) Standard, HRC, IRC |
| IPTV | Pass-Through IPTV Stream from Received Channel Selectable Individual or All Programs |
| Decoding | Video: MPEG2, H.264: 1080p, 1080i, 720p, 480p, 480i Audio: AC3, MP1-2, AAC |
| Video Output | 3G-HD/SD/SDI: 1 x BNC (Level A) HDMI: 1 x HDMI 1.3, Type A |
| Audio | SSI & HDMI: AC-3/PCM/PCM Variable Level Digital Audio SPDIF: Coax & Optical Output, AC-3/PCM/PCM Variable Level Analog Audio: Stereo RCA Output, Variable Level |
| Control | 10/100 Ethernet: 1 x RJ-45 (Web Page Access, Telnet, UDP Control) RS-232: 1 x DB9 (Male, 1200 to 230K Baud, 8 Data Bits, No Parity, 1 Stop Bit) IR Input: 1 x 3.5 mm Stereo Jack (for Optional IR-RXC Receiver) AC Power Output: 1 x 3.5 mm (for Optional RF-AB Air/Cable Selector Switch) |
| Front Panel | Display LCD Text (White on Blue) Buttons Power, Menu, Setup, Select Up, Down (Channel) Left, Right (Volume) Control: 1 x IR Sensor USB: 1 x USB Mini-B |
| Video Output Resolution | HDMI 1080p 60 1080i 60/59.94 720p 60/59.94 SDI 1080p 60 1080i 60/59.94 720p 60/59.94 |
| Rack Height | 1 RU |
| Dimensions (WxDxH) | 8.5 x 8 x 1.7" / 21.6 x 20.3 x 4.4 cm |
| Weight | 1.8 lb / 822 g |
| Package Weight | 3.195 lb |
| Box Dimensions (LxWxH) | 15 x 10.4 x 3.2" |
