The Schneider Optics�21-1070400 Xenon-Emerald V Mount Lens (100mm / f2.8) can be used for close up or infinity range, and is optimized for a uniform image quality over the whole sensor area. This low distortion lens, with an image circle diameter of 43.2mm, is compact, robust, and lockable in distance and aperture. The 400 to 1000 nm broadband coating makes it suitable for applications in the visible and near-infrared spectrum. The option of alternative mounts like the Canon bayonet or M42 thread (sold separately) makes the lens even more flexible for a wide range of applications in machine vision, quality control, web inspection, and other image processing applications.
- Robust mechanics for rough industrial environment
- Compact design and low weight
- Focus and iris setting lockable
- High resolution optics 400 to 700 nm (VIS) / 700 to 1000 nm (NIR)
- Corrected for close up range
- Constant MTF over the entire image field
- Applications - Machine vision and other imaging applications, quality control, web inspection, surface inspection, line scan applications
In the Box
Schneider 21-1070400 Xenon-Emerald V Mount Lens (100mm / f2.8)
| F-Number (f) | 2.8 |
| Focal Length | 100.1 mm |
| Image Circle | 43.2 mm |
| Transmission | 400 to 1000 nm |
| Interface | V mount |
| Weight | 16.33 oz (463 g) |
