Description
Route, process, and transmit audio signals in Dante networks with this Dante 8-Channel Audio DSP from MuxLab, a high-quality, low-latency digital and analog audio processor with 8-way analog audio inputs and outputs. An integrated USB sound card supports single-channel audio input and output, and the device can be controlled via RS-232, RS-485, and TCP/IP. System automation can be achieved via comprehensive API commands with support for advanced DSP algorithms facilitating options such as AEC, AFC, ANC, Ducker, Compressor, Limiter, Mixer, and Graphic Equalization, while supporting multiple sets of scene presets.
| Features | Analog Maximum Gain: 51 dB Quantization Bits: 24-Bit Sample Rate: 48 kHz Frequency Response: 20 Hz-20 KHz ± 0.25 dB THD+N: ≤0.003% at 1 KHz, +4 dBu Digital/Analog Dynamic Range: 114 dB Analog/Digital Dynamic Range: 120 dB Input Impedance: 20k Ohms Balanced，10k Ohms Unbalanced Output Impedance 100 Ohms Balanced, 50 Ohms Unbalanced Maximum Input Level: 18 dBu, Balanced Maximum Output Level: 18 dBu, Balanced Input Common Mode Rejection: 84 dB at +24 dBu at 60 Hz Channel Isolation: >104 dB |
| USB I/O | 1 x USB-A Female Input 1 x USB-A Female Output |
| Audio I/O | 1x RJ45 Dante Input 1x RJ45 Dante Output 8x Block Line Input 8x Block Line Output |
| Other I/O | 1 x RJ45 (Ethernet) 1 x RS-485 Serial Port 1 x RS-232 Serial Port |
| Power Source | AC Input (Built-In) |
| AC Input Power | 110 to 220 VAC, 50 / 60 Hz |
| Phantom Power | 48 VDC |
| Mounting | 4x Screw Holes |
| Color | Black |
| Certifications | CE, FCC, RoHS |
| Operating Conditions | 32 to 104°F / 0 to 40°C |
| Package Weight | 8.515 lb |
| Box Dimensions (LxWxH) | 23.4 x 13.5 x 4.7" |
