Description
Quest Commercial M-35 Overview
Designed as an ideal selection for a wide range of commercial and retail applications, the M35 Compact Mixer and Amplifier from Quest Commercial is a straightforward yet versatile amplifier and mixer combo that provides up to 35W of power for passive speakers and sports an internal transformer for 25 and 70V distribution or direct 4- or 8-ohm operation. The M35 makes it easy to feed virtually any sound source into one of the amps three channels, and dedicated knob controls for source volume, master volume, and 2-band EQ let you quickly make adjustments on the fly.
The M35 includes a plethora of I/O connections in terminal block, RCA, and front-panel 3.5mm forms for connecting media players, wireless mic systems, phantom-powered microphones, and even paging and telecom systems with the dedicated MOH output, making this system great for commercial telephone networks that require background music. With built-in protections like overcurrent, DC offset, and thermal protections, you never have to worry about harming your speakers or amplifier.
- Channel 1: This mic/line input channel is designed specifically to accept microphone inputs and is the only channel equipped with switchable phantom power
- Channel 2: This channel features separate block terminal mic and RCA line inputs
- Channel 3: This channel features separate block terminal mic and RCA line inputs as well as a 3.5mm stereo aux input located on the front panel
In the Box
- Quest Commercial M35 Compact 35W Amplifier and Mixer
- Limited 3-Year Manufacturer Warranty
Quest Commercial M-35 Specs
| Number of Channels |
3 Input
|
| Amplifier Power Rating |
1x 35 W (0.5% THD)
|
| Load Impedance / Voltage |
25 / 70 V (9.6 Ohms Nominal)
4 / 8 Ohms |
| Audio I/O |
1x Block 3-Pin Line/MOH Output (Detachable)
1x Block 3-Pin Balanced Mic Input (Detachable) 2x Block 3-Pin Mic Input (Detachable) 1x Block 3-Pin Page/Telephone Input (Detachable) 2x Stereo RCA Coaxial Unbalanced Line Input 1x 1/8" / 3.5 mm TRS Aux Input (Front Panel) |
| Digital Audio I/O |
No
|
| Network I/O |
No
|
| USB I/O |
No
|
| Form Factor/Type |
Tabletop (Rack-Mountable with Optional Hardware)
|
| Number of Channels |
3 Input
|
| Number of Zones |
1
|
| Amplifier Power Rating |
1x 35 W (0.5% THD)
|
| Load Impedance / Voltage |
25 / 70 V (9.6 Ohms Nominal)
4 / 8 Ohms |
| Protections |
DC Offset, Overcurrent, Thermal
|
| Frequency Response |
80 Hz to 18 kHz ±3 dB
|
| Input Sensitivity |
Block Mic:
-50 dB (Balanced) Block / RCA Aux: -30 dB (Unbalanced) Block Page/Telephone: -21 dB (Unbalanced) |
| I/O Impedance |
RCA/Block Line/Mic/Telephone Input:
20 Kilohms (Balanced, Mic In) 47 Kilohms (Unbalanced, Line In) 600 Ohms (Unbalanced, Telephone In) Block MOH Output: 600 Ohms (Balanced) |
| SNR |
< 90 dB
|
| THD |
< 0.5%
|
| Crosstalk |
-70 dB
|
| EQ |
2-Band Semi-Parametric EQ:
Treble: ±10 dB Bass: ±10 dB |
| Ducking/Muting |
Yes
|
| Audio I/O |
1x Block 3-Pin Line/MOH Output (Detachable)
1x Block 3-Pin Balanced Mic Input (Detachable) 2x Block 3-Pin Mic Input (Detachable) 1x Block 3-Pin Page/Telephone Input (Detachable) 2x Stereo RCA Coaxial Unbalanced Line Input 1x 1/8" / 3.5 mm TRS Aux Input (Front Panel) |
| Digital Audio I/O |
No
|
| Network I/O |
No
|
| Speaker Outputs |
1x Block 5-Pin 4-Ohm/8-Ohm/Low-Z/25 V/70 V Main (Detachable)
|
| Number of Module Slots |
No
|
| USB I/O |
No
|
| Phantom Power |
Yes
|
| Mobile App Compatible |
No
|
| Wireless |
No
|
| Media/Memory Card Slot |
No
|
| AC Input Power |
110 VAC, 50 / 60 Hz
|
| AC Power Connector |
1x Hardwired Cord
|
| AC Outlet |
No
|
| Display & Indicators |
5x LED (Clip/Peak/Power/Protect/Signal)
|
| Cooling |
Convection
|
| Dimensions |
10.6 x 3.0 x 9.1" / 26.9 x 7.6 x 23.1 cm
|
| Weight |
7.1 lb / 3.2 kg
|
| Package Weight |
8.69 lb
|
| Box Dimensions (LxWxH) |
14.4 x 13.6 x 6.6"
|
