Description
Hanwha Vision SPA-B1000 Overview
The Hanwha Vision SPA-B1000 is an IP audio bridge designed to convert analog audio signals into digital streams over IP networks. Compact and mountable, this device is ideal for applications such as background-music distribution, public-address systems, and integration with IP-based security and communication systems in educational institutions, retail spaces, and corporate settings.
- Analog Audio Input: Supports left and right channels with a maximum input level of +6 dBV.
- Storage: Equipped with 1GB of internal memory and a microSD slot supporting SDHC cards up to 32GB (SanDisk recommended).
- Audio Formats: Compatible with WAV and MP3 files in mono or stereo, ranging from 64 to 320 kbps, with sampling rates between 16 and 48 kHz.
- Power Options: Operates via Power over Ethernet (PoE, IEEE 802.3af Type 1, Class 0) or 24 VDC with an optional power supply.
- Network Protocols: Supports IPv4, HTTP, HTTPS, SIP, mDNS, DNS, NTP, TCP, UDP, DHCP, ARP, ICMP, and SNMP(v3).
- Security Features: Includes password protection with multiple user levels, digest authentication, user-access logs, IP filtering, and IEEE 802.1X support (EAP-TLS, EAP-LEAP, EAP-PEAP, MSCHAPv2).
- System Integration: Offers SUNAPI (HTTP API) for integration with other systems, along with virtual contact and dry contact event presets.
Items Included
- Hanwha Vision SPA-B1000 IP Audio Bridge
- Audio-Input Cable with 3.5mm Stereo Female Jack
- Limited 5-Year Manufacturer Warranty
Additional Resources
No additional resources available
Hanwha Vision SPA-B1000 Specs
| Audio |
Line Input (L/R): +6 dBV, Max.
File Streaming: WAV, MP3 in Mono/Stereo from 64 to 320 kbps/ 16 up to 48 kHz |
| Network |
Ethernet: 10/100 Base-T
|
| Memory |
Internal Memory 1 GB
External Memory: microSD up to 32 GB |
| Contacts |
Contact Input: Dry Contact, 1 x Channel
Contact Output: Dry Contact (NO), 1 x Channel |
| Supported Protocols |
IPv4, HTTP, HTTPS, mDNS, DNS, NTP, TCP, UDP, DHCP, ARP, ICMP
|
| System Integration |
API (Application Programming Interface): SUNAPI
Event and Preset: Virtual Contact, Dry Contact Functional Monitoring: Connection Verification, Built-In System Logging |
| Security |
Password Protection : Admin Setup, User, Guest
|
| Power |
PoE (IEEE 802.3af Type 1, Class 0), 24 VDC (with Optional Power Supply)
|
| Operating Temperature |
-4 to +122°F / -20 to +50°C
|
| Operating Humidity |
10 to 95% RH (Noncondensing)
|
| Connector 1 |
1x RJ45
|
| Connector 2 |
1x 4-Terminal Euroblock
1x 3-Terminal Euroblock |
| Color |
White
|
| Certifications |
EN, FCC, ICES, KC, UL
|
| Cable Length |
Not Specified by Manufacturer
|
| Dimensions |
4.8 x 3.1 x 1.2" / 123 x 80 x 30.6 mm
|
| Weight |
0.5 lb / 240 g
|
| Package Weight |
0.78 lb
|
| Box Dimensions (LxWxH) |
7.8 x 6 x 1.9"
|
