Description
AtlasIED HPA2408 Overview
The black Atlas Sound HPA2408 is an eight-channel 2400W commercial amplifier offering 300W per channel, support for 2-ohm, 4-ohm, 8-ohm, 70V, and 100V operation, and expandability via a separately available Dante card. By utilizing Generation II Class-D topology, this HPA Series amp delivers high power and enhanced efficiency along with sound quality akin to a Class-AB amplifier.
The switch mode, auto-sensing universal power supply ensures that a reliable output is achieved even when receiving inconsistent power voltages. Together, the power supply and output circuitry yield peak performance with a variety of speaker loads while remaining energy efficient and compact.
Detented attenuators enable easy level adjustments while their security cover prevents unwanted changes to amp gain. With fault reporting, remote turn-on functionality, and informative front-panel LED indicators, the HPA2408 is ideal for commercial distributed systems, contractor applications, houses of worship, and more.
- Ideal for clubs, house of worship systems, portable sound systems, convention centers, sports venues, hotels, and retail centers
- Eight channels at 300W per channel
- 2-ohm, 4-ohm, 8-ohm, 70V, and 100V operation
- Low-resistance, direct-coupled thermal transfer design maintains an optimal temperature across all loads and output levels
- Meets Energy Star standards, drawing just 1W of power in standby mode
- Balanced line inputs on Euroblock connectors
- Rear-panel accessory card slot for separately available Atlas HPA-DAC8 Dante eight-channel digital audio interface card
- Stereo or parallel operating modes
- Selectable input sensitivity
- High-efficiency fan cooling
- Auto-sensing 100 to 240 VAC mains power supply
- Occupies 2 RU of rack space
Items Included
- AtlasIED HPA2408 Eight-Channel 2400W Commercial Amplifier (Black)
- Security Cover for Level Controls
- Set of Block Connectors
- IEC C19 to NEMA 5-20P Power Cable
- Limited 3-Year Manufacturer Warranty
Additional Resources
No additional resources available
AtlasIED HPA2408 Specs
| Number of Channels |
8
|
| Amplifier Power Rating |
4 Ohms / 8 Ohms / 25 V / 70 V / 100 V:
8x 300 W per Channel |
| Load Impedance / Voltage |
70 / 100 V
|
| Analog Audio I/O |
8x Block 2-Pin Input
8x Block 3-Pin Output |
| Digital I/O |
No
|
| Network I/O |
No
|
| Rackmount Size |
2 U
|
| Number of Channels |
8
|
| Amplifier Power Rating |
4 Ohms / 8 Ohms / 25 V / 70 V / 100 V:
8x 300 W per Channel |
| Amplifier Class |
Class-D
|
| Load Impedance / Voltage |
70 / 100 V
|
| Protections |
DC Fault, Thermal, Undervoltage
|
| Frequency Response |
20 Hz to 20 kHz
|
| Input Sensitivity |
0.775 V to 1 V / 32 dB
|
| Input Impedance |
100 Ohms (Balanced)
|
| Max Gain |
36 dB (at 8 Ohms)
39 dB (at 70 V) |
| Max Voltage Swing |
At 8 Ohms: 49 V
|
| SNR |
> 70 dB
|
| THD |
0.15%
|
| Crosstalk |
> 60 dB
|
| Slew Rate |
> 8 V/?s
|
| Crossover |
Yes
|
| Limiting |
Yes
|
| Analog Audio I/O |
8x Block 2-Pin Input
8x Block 3-Pin Output |
| Digital I/O |
No
|
| Network I/O |
No
|
| USB I/O |
No
|
| Mobile App Compatible |
No
|
| Wireless |
No
|
| AC Input Power |
100 to 240 VAC, 50 / 60 Hz
|
| AC Power Connector |
1x IEC (Locking)
|
| Power Consumption |
2.7 W (Standby)
2741 W (Max) |
| Display & Indicators |
LED
|
| Rackmount Size |
2 U
|
| Cooling |
Fan
|
| Dimensions |
19.0 x 3.5 x 15.0" / 483.0 x 89.0 x 381.0 mm
|
| Weight |
21.4 lb / 9.7 kg
|
| Package Weight |
33.61 lb
|
| Box Dimensions (LxWxH) |
22.6 x 22.1 x 6.6"
|
