Description
The ASP-MG24TDB advances sound masking control including time based level control to another level while providing the secondary benefit of loudspeaker processing for the most popular AtlasIED loudspeaker systems.
The ASP-MG24 is 1RU, 2 input with 4 masking generators x 4 output DSP configurable by a very intuitive set-up GUI. Four inputs are tied to independent white/pink noise generators with adjustable ramp-up to allow gradual acclimation to masking levels. Two additional inputs are available for mic or line sources to allow paging and/or music sources to be blended with the masking sources to any of the 4 outputs.
Dedicated 1/3 octave filter sets are available for each of the 4 generator outputs, 8 band parametric EQ blocks along with dynamic control is available for each of the two mic/line inputs. Any mix of all 6 inputs may be easily matrixed to the 4 output DSP blocks for additional parametric equalization, delay, and limiting (if required).
Factoring in all features, a very complex 4 zone sound masking system can be easily configured with 2 external music or page sources. The MGTDB internal module allows timing and level control of all 4 Masking inputs for daytime holiday and weekend scheduling.
- Key Features
-
- Easy downloads from the Atlas Sound MEQ masking program make system tuning a breeze
- The ASP-MG24 DSP architecture is equally suited for complex masking systems and for control of atlas sound full range speakers and/or subwoofers
- The ASP-MG24TDB provides accurate detailed control over masking levels for all 4 masking generators based on an easy to use scheduler
- The Intuitive ASP-MG24 set-up GUI is designed to simplify even complex setups that utilize multiple sources plus masking in the same zone
| General | |
|---|---|
| Type | Speaker management processor |
| Width | 19 in |
| Depth | 8 in |
| Height | 1.7 in |
| Weight | 13.23 lbs |
| Studio & Production Equipment | |
|---|---|
| Features | Scheduling function |
| Power | |
|---|---|
| Max Power Consumption | 20 W |
| Terminals | |
|---|---|
| Terminals | (1) x USB - 4 pin USB type B (1) x serial - 9 pin D-Sub (DB-9) (2) x balanced audio input - terminal block (4) x balanced audio output - terminal block (1) x network - RJ-45 |
| Manufacturer Warranty | |
|---|---|
| Warranty | 1 year |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.
Bulk Discount
| Quantity | Price |
| 2 | ₹ 385100.8 |
| 3-5 | ₹ 381171.2 |
| 5-10 | ₹ 373312.0 |
| 10+ | ₹ 365452.8 |
Bulk discount will be automatically applied during checkout based on quantity.
