Description
Teledyne Flir 4MP Color Camera Overview
The Blackfly S GigE 0.4MP Color Camera from Teledyne Flir captures up to 720 x 540 resolution video and offers Gigabit Ethernet output. Maximum standard frame rate is 291 fps and with turbodrive and lossless compression it has a maximum of 350 fps. Featuring a compact form factor, the high-performance camera is designed for industrial machine vision applications and meets the GigE Vision v1.2 standard. A CS lens mount provides support for a wide variety of varifocal and fixed focal length lenses.
Features include a Sony IMX287 1/2.9" CMOS color sensor, two custom user settings, manual/auto gain and white balance, and a global shutter. You can power the camera using a 6-pin Hirose power source or via PoE using an optional interface card.
- Acquisition modes: Continuous / Single Frame / Multi frame
- Exposure control: hardware trigger, programmable via camera API, automatic
- Exposure range: 4 µs to 30 seconds
- Flash memory: 6MB non-volatile memory
- Gain control: manual, automatic (AGC)
- Image buffer: 240MB
- Image processing: color correction matrix, gamma, lookup table, saturation, and sharpness
- Partial image modes: pixel binning, decimation, ROI
- User sets: two user configuration sets for custom camera settings
- White balance: manual, automatic (AWB)
- Absolute sensitivity threshold (y): 7.10
- Dynamic range: 74.29 dB
- Gain range: 0 to 47 dB
- Quantum efficiency blue: 52 at 470nm
- Quantum efficiency green: 61 at 525nm
- Quantum efficiency red: 48 at 630nm
- Saturation capacity (e-): 22346
- Temporal dark noise (read noise): 3.81
Items Included
- Teledyne Flir Blackfly S GigE 0.4MP Color Camera (CS Mount)
- Limited 3-Year Manufacturer Warranty
Additional Resources
No additional resources available
Teledyne Flir 4MP Color Camera Specs
| Compatibility |
Not Specified by Manufacturer
|
| Sensor |
Sony IMX287 1/2.9" CMOS, 0.4 MP
|
| Shutter |
Global
|
| Spectral Range |
Color
|
| Lens Mount |
CS
|
| Resolution |
720 x 540
|
| Frame Rate |
Max Frame Rate Standard: 291 fps
Max Frame Rate Turbodrive/Lossless Compression: 350 fps |
| Other I/O |
1 x RJ45, Gigabit Ethernet (PoE, Video)
1 x 6-Pin Hirose (Power) |
| Power Source |
PoE (Not Included), Plug-In Power (Not Included)
|
| DC Input Power |
5 to 16 VDC at 120 mA
|
| Power Consumption |
2.5 W
|
| Color |
Black
|
| Certifications |
CE, FCC, Kcc, RoHS
|
| Operating Conditions |
32 to 113°F / 0 to 45°C at 20 to 80% Humidity
|
| Storage Conditions |
-22 to 140°F / -30 to 60°C at 20 to 95% Humidity
|
| Cable Length |
Not Specified by Manufacturer
|
| Dimensions |
1.2 x 1.1 x 1.1" / 30 x 29 x 29 mm
|
| Weight |
1.3 oz / 36 g
|
| Package Weight |
0.2 lb
|
| Box Dimensions (LxWxH) |
4.6 x 3.2 x 2.15"
|
