Description
JAI Pregius S Overview
The Go-X 5.1MP Pregius S 4th Gen Camera from JAI is a compact, industrial area scan camera with a state-of-the-art 1/1.8" Sony Pregius X global shutter sensor with backside illumination (BSI) technology. Equipped with a C-mount lens mount, the camera integrates a 5 GigE interface and captures 5.1MP monochrome images with 2472 x 2064 resolution at 103 fps. It offers 8-, 10-, and 12-bit video output and sequencer and automatic level control. The shock- and vibration-resistant unit powers over PoE (Power over Ethernet) or via the integrated 6-pin Hirose port using an optional power cable.
Built for Non-Stop Operation
Go-X Series cameras are built to withstand the shock, vibration, and thermal demands of typical industrial environments, so they can keep critical inspection systems running 24/7, 365 days a year.
Pre-Screened for Dust & Other Particles
Special dust-prevention measures include clean room assembly, internal seals around the sensor compartment, and a pre-screening process to ensure every camera shipped delivers the best-possible image quality via a clean, dust-free optical path.
Backside Illumination Pixel Technology
The small but highly sensitive 2.74-micron pixels to pack more resolution into less silicon, so you get more megapixels for your money. The backside illumination (BSI) pixel technology delivers low-noise and high-light sensitivity, matching the image quality of sensors with much larger pixels.
Additional Details
- 5.1MP camera and 1/1.8" optical format
- Backside-illuminated Sony Pregius S CMOS image sensor
- High-performance GigE Vision 2.0 interface
- Can be powered over the interface (PoE) or from an optional external power supply via 6-pin Hirose connector
- Small and lightweight to mount easily on robotic arms, UAVs, and any other machine vision systems where motion or portability are vital
- Mounting holes to fit most existing installations with no re-tooling required
- Industrial grade performance with ratings of 80G shock, 10G vibration, and optimal thermal dissipation
- Includes new "Xscale" function supporting virtual, sub-pixel rescaling of output for greater binning flexibility or when matching the resolution and FOV of cameras in existing systems
Items Included
- JAI Go-X 5.1MP Pregius S 4th Gen Camera (5GigE, Monochrome)
- Limited 6-Year Manufacturer Warranty
Additional Resources
JAI Pregius S Specs
General
| Type |
Area Scan
|
| Lens Mount |
C-Mount
|
| Interface |
5 Gb/s GigE Vision (PoE)
|
| Image Sensor |
1/1.8" IMX547 Pregius S 5.1MP Monochrome Sensor
|
| Sensor Resolution |
2472 x 2064
|
| Frame Rate |
103 fps
|
| Shutter Type |
Global
|
| Video Output |
8/10/12-Bit
|
Power
| Power Source |
PoE (Built-In), Plug-In Power (Not Included)
|
| DC Input Power |
10 to 57 VDC
|
| Power Consumption |
5.4 W
|
Physical
| Mounting |
Multiple M3 Threaded Holes
|
| Color |
Black / Green
|
| Certifications |
CE, EU, FCC, KC, RoHSChina, RoHS, WEEE
|
| Operating Conditions |
23 to 113°F / -5 to 45°C at 20 to 80% Humidity
|
| Storage Conditions |
-13 to 140°F / -25 to 60°C at 20 to 80% Humidity
|
| Dimensions |
2.7 x 1.1 x 1.1" / 68 x 29 x 29 mm
|
| Weight |
3.4 oz / 95 g
|
