Description
ARX MaxiSPLIT Overview
The ARX MaxiSPLIT is a professional line-level distribution splitter designed for modern multi-zone installations, studio setups, live sound, and broadcast environments. With two independent 1-in/4-out channels?or a switchable 1-in/8-out mono mode?the MaxiSPLIT offers exceptional flexibility for routing audio to multiple zones or destinations with precise control.
Flexible Dual-Mode Signal Routing
Each channel features electronically balanced XLR inputs (male and female) and four balanced XLR outputs, each with individual gain control and up to +6 dB of output trim. Thanks to ARX's carefully engineered signal path, the MaxiSPLIT delivers ultralow noise, high headroom, and pristine signal integrity across all outputs.
Reliable Performance with Professional Features
Mode selection is handled via a rear-panel switch, with corresponding LED indicators on the front panel for clear status monitoring. Whether you're distributing feeds in an installed AV system, routing effects in a studio, or splitting signals in a live or OB environment, the MaxiSPLIT is built to handle it all with precision and reliability.
Additional Details
- Two independent 1:4 splitters: each channel operates independently with its own input and four outputs
- 1:8 mono split mode: link channels to create a single input with eight outputs
- Individual output level controls: each output has its own front-panel gain control (up to +6 dB)
- Balanced I/O: electronically balanced XLR connectors with RF filtering on inputs
- Wide dynamic range: low distortion and high headroom ensure clean, consistent audio
- Front-panel indicators: LED status lights show active mode; marker panel for labeling outputs
- Universal power supply: switchable 100?120V / 220?240V AC input with IEC connection and built-in fuse
- Compact and rack-ready: ideal for permanent installations or mobile rigs
Items Included
- ARX MaxiSPLIT 2-Channel Line Distribution Splitter
- IEC Power Cord
- Limited 12-Month Manufacturer Warranty (Labor)
- Limited 24-Month Manufacturer Warranty (Parts)
Additional Resources
No additional resources available
ARX MaxiSPLIT Specs
Inputs/Outputs
| Audio I/O |
2x XLR 3-Pin Input
10x XLR 3-Pin Output |
Wireless
| Mobile App Compatible |
No
|
Power
| Power Source |
AC Input (Included)
|
| AC Input Power |
100 to 240 VAC, 50 / 60 Hz
|
Physical
| Mounting |
Side: 2x Rack Ears
|
| Color |
Gray
|
Packaging Info
| Package Weight |
6.2 lb
|
| Box Dimensions (LxWxH) |
21.4 x 10 x 2.5"
|
