The 507002B00000G is a wide hat section Heat Sink for use with TO-220 and single-gauge (0.02-inch) TO-220 packages. This 6070B heat sink is made of aluminium with black anodize finish.
- Vertical and horizontal mount orientation
Applications
HVAC, Thermal Management
Product details
| Thermal Resistance |
15.6°C/W |
| Packages Cooled |
TO-220 |
| External Width - Metric |
44.45mm |
| External Height - Metric |
9.52mm |
| External Length - Metric |
17.78mm |
| External Diameter - Metric |
- |
| Heat Sink Material |
Aluminium |
| External Width - Imperial |
1.75" |
| External Height - Imperial |
0.375" |
| External Length - Imperial |
0.7" |
| External Diameter - Imperial |
- |
| Product Range |
- |
Other details
| Brand |
BOYD |
| Part Number |
507002B00000G |
| Quantity |
Each |
| Technical Data Sheet EN |
 |
