| ₹ 22928.43 includes GST and import duties. | |
| B2B customers can avail ₹ 3496.59 ITC on this product | |
| 100% Secure Payments | 100% Genuine product | |
| The product is eligible for Free Shipping |
Description
The S8VS03012 is a 12V/30W 1-output switch mode Power Supply with indication monitor, screwless terminal blocks and simple functions for easy system commissioning. Side-by-side mounting directly in panels is possible. Mount to DIN-rail and lead-free solder. This power supply output is fixed.
- Overvoltage protection
- Red undervoltage alarm indication
- 25 to 85% Operating ambient humidity
- 3kVAC for one minute (between all inputs and outputs, detection current 20mA) Dielectric strength
- 100MR min (between all outputs and all inputs/PE terminals) at 500VDC Insulation resistance
Applications
Power Management
Product details
| Power Supply Output Type | Fixed |
| Output Power Max | 30W |
| Output Voltage - Output 2 | - |
| Output Current - Output 2 | - |
| Input Voltage AC Max | 264VAC |
| Input Voltage AC Min | 85VAC |
| Product Range | - |
| Output Voltage - Output 3 | - |
| Output Voltage - Output 1 | 12VDC |
| Output Current - Output 3 | - |
| Output Current - Output 4 | - |
| No. of Outputs | 1 Output |
| Output Voltage - Output 4 | - |
| Output Current - Output 1 | 2.5A |
Other details
| Brand | OMRON INDUSTRIAL AUTOMATION |
| Part Number | S8VS-03012 |
| Quantity | Each |
| Technical Data Sheet EN |  |
| Product Change Notice EN | |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
Bulk Discount
| Quantity | Price |
| 2 | ₹ 22469.86 |
| 3-5 | ₹ 22240.58 |
| 5-10 | ₹ 21782.01 |
| 10+ | ₹ 21323.44 |
Bulk discount will be automatically applied during checkout based on quantity.
