| ₹ 362.04 includes GST and import duties. | |
| B2B customers can avail ₹ 55.21 ITC on this product | |
| 100% Secure Payments | 100% Genuine product |
Description
The M50-3550542 is a 10-contact 2-row 1.27mm male Board-to-board Ejector Pin Header with gold plated brass contacts, 100% tin over nickel plated termination and black UL94V-0 LCP housing. The M50 series plug has 2.7mm PC tail, vertical connector orientation and PC tail/through board connection type. Shrouded for robust pin protection, polarised to prevent mismating. It is suitable for use with 0.4mm square mating pin size. Mates with IDC cable connector M50-3300542 or associated cable assemblies.
- 1.5A Current rating
- 20mR Maximum contact resistance
- 5000MR Minimum insulation resistance
- 1000VACrms/DC for one minute Dielectric strength
Applications
Commercial, Industrial
Product details
| No. of Contacts | 10Contacts |
| Contact Plating | Gold Plated Contacts |
| Gender | Header |
| Product Range | M50 Series |
| Contact Material | Brass |
| Contact Termination Type | Through Hole |
| Pitch Spacing | 1.27mm |
| No. of Rows | 2Rows |
Other details
| Brand | HARWIN |
| Part Number | M50-3550542 |
| Quantity | Each |
| Technical Data Sheet EN |  |
| Drawing EN | |
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them. Image is for illustrative purposes only. Please refer to product description.
Bulk Discount
| Quantity | Price |
| 2 | ₹ 354.8 |
| 3-5 | ₹ 351.18 |
| 5-10 | ₹ 343.94 |
| 10+ | ₹ 336.7 |
Bulk discount will be automatically applied during checkout based on quantity.
