- Medical 3rd Edition Safety Approvals
- 2 x MOPP
- 4000 VAC Reinforced Insulation
- 2 �A Patient Leakage Current
- DIP-24 Package
- Operating temperature range -40�C to +80�C
- EN55011 Level A With No External Components
Product details
| Output Power Max |
10W |
| Input Voltage DC Min |
9V |
| DC / DC Converter Mounting |
Through Hole |
| Output Voltage - Output 2 |
- |
| Output Current - Output 2 |
- |
| Depth |
31.75mm |
| Width |
20.32mm |
| Product Range |
JHM10 Series |
| DC / DC Converter Type |
DIP |
| Approvals & Standards |
CSA 22.2 No. 60601, ES 60601, IEC 60601 |
| Output Voltage - Output 3 |
- |
| Output Voltage - Output 1 |
12V |
| Output Current - Output 3 |
- |
| No. of Outputs |
1 Output |
| DC / DC Converter Output Type |
Fixed |
| Input Voltage DC Max |
18V |
| Output Current - Output 1 |
833mA |
| Height |
12.7mm |
Other details
| Brand |
XP POWER |
| Part Number |
JHM1012S12 |
| Quantity |
Each |
