Description
The MJL1302AG is a -260V PNP Bipolar Complementary Power Transistor designed for use in high end consumer audio products and professional audio amplifiers such as theatre and stadium sound systems as well public address systems (PAs).
- Exceptional safe operating area
- Excellent gain linearity
- High BVCEO
- High frequency
- Reliable performance at higher powers
- Symmetrical characteristics in complementary configurations
- Accurate reproduction of input signal
- Greater dynamic range
- High amplifier bandwidth
Applications
Audio, Consumer Electronics
Product details
| Power Dissipation Pd | 200W |
| DC Collector Current | 15A |
| Collector Emitter Voltage V(br)ceo | 200V |
| Transition Frequency ft | 30MHz |
| Operating Temperature Max | 150°C |
| Transistor Polarity | PNP |
| DC Current Gain hFE | 175hFE |
| No. of Pins | 3Pins |
| Product Range | - |
| Automotive Qualification Standard | - |
| Transistor Case Style | TO-264 |
| MSL | - |
Other details
| Brand | ON SEMICONDUCTOR |
| Part Number | MJL1302AG |
| Quantity | Each |
| Technical Data Sheet EN |  |
|
|
| Product Change Notice EN | |
