Description
The M22-6360542 is a 10-contact 2mm female DIL Board-to-board Socket with gold plated phosphor bronze contacts, 100% tin over nickel plated termination and black UL94V-0 polyamide (nylon) 6T housing. The M22 series connector has vertical connector orientation, surface mount (SMT) connection type and dual entry (bottom entry, top entry). It is suitable for use with 0.5mm square mating pin size. Twin beam contact for cost-effective reliability.
- 2A Current rating
- 20mR Maximum contact resistance
- 1000MR Minimum insulation resistance
- 500VAC Minimum dielectric strength
Applications
Commercial, Industrial
Product details
| No. of Contacts | 10Contacts |
| Contact Plating | Gold Plated Contacts |
| Gender | Receptacle |
| Product Range | M22 Series |
| Contact Material | Phosphor Bronze |
| Contact Termination Type | Surface Mount |
| Pitch Spacing | 2mm |
| No. of Rows | 2Rows |
Other details
| Brand | HARWIN |
| Part Number | M22-6360542 |
| Quantity | Each |
| Technical Data Sheet EN |  |
| 3D Product Image EN | |
