Product details
DC Resistance Max - Parallel |
0.05ohm |
Saturation Current - Parallel |
2.8A |
Product Range |
MSD7342 Series |
Coupled Inductor Case |
7.5mm x 7.5mm x 4.6mm |
Inductance, Parallel |
10�H |
Packaging |
Cut Tape |
RMS Current - Parallel |
1.24A |
Other details
Brand |
COILCRAFT |
Part Number |
MSD7342-103MLB |
Quantity |
Each (Supplied on Cut Tape) |
Technical Data Sheet EN |
 |
