AMD XC6SLX25-3FGG484I FPGA, Spartan-6, DCM, PLL, 226 I/O, 24051 Macrocells, 1.14V to 1.26 V, FBGA-484, NCNR

XC6SLX25-3FGG484I is a Spartan-6 LX logic optimized family, 45nm technology FPGA (Field Programmable Gate Array). This FPGA offers a new, more efficient, dual-register 6-input lookup table (LUT) logic and a rich selection of built-in system-level blocks. This include 18Kb (2 x 9Kb) block RAMs, second generation DSP48A1 slices, SDRAM memory controllers, enhanced mixed-mode clock management blocks, SelectIO technology, power optimized high-speed serial transceiver blocks, PCI Express® compatible endpoint blocks, advanced system-level power management modes, auto-detect configuration options, and enhanced IP security with AES and Device DNA protection. These features provide a low-cost programmable alternative to custom ASIC products with unprecedented ease of use. XC6SLX100-3FGG676I FPGAs offer the best solution for high-volume logic designs, consumer-oriented DSP designs, and cost-sensitive embedded applications.

• 24051 logic cell
• Configurable Logic Blocks (CLBs): 3758 slices, 30064 flip flop and 229kb max distributed RAM
• Block RAM blocks: 52 x 18Kb block and 936KB max
• 38 DSP48A1 slices, 2 CMTs and 2 memory controller blocks max
• 4 total I/O banks and 266 max user I/O
• Low static and dynamic power (High performance 1.2V core voltage)
• Multi-voltage, multi-standard SelectIO� interface banks ( 3.3V to 1.2V I/O standards and protocols)
• Simplified configuration, supports low-cost standards
• Enhanced security for design protection
• 484 pin FBGA and Industrial temperature range from -40°C to +100°C

Notes

Please note this product is Non-Cancellable and Non-Returnable (NCNR). Warranty Information: Xilinx semiconductor products have a warranty of twelve (12) months from date of purchase.
