Description
The San Ace 60W series 9WL type Splash Proof DC Fan can be installed in outdoor environments exposed to water, suitable for cooling solar inverters and equipment for outdoors use. The 9WL type series fans provide efficient cooling for devices with high quality and high reliability, overheating protection function. If the fan blades are restricted, an over-current occurs and leads to a rise in the fan coil temperature. This can result in reduced performance, damage or a fire. To prevent this from occurring, SANYO DENKI's fans incorporate an overheating protection function. If the fan blades are restricted, the coil current is cut off at regular cycles to prevent overheating of the coil. When the hindrance is removed, the fan restarts automatically. No problem about fan even if positive and negative leads are connected in reverse. However, when wiring fans with sensors or PWM speed control function, connecting positive and negative leads in reverse may damage the fans.
- Burnout protection function at locked rotor condition
- Reverse polarity protection function
- 10MR at 500VDC Insulation resistance
- UL94V-1 Flammability rated plastic impeller and aluminium frame (black coating)
- 180000/60°C Hours expected life
- High airflow long life fan
Warnings
Market demand for this product has caused an extension in leadtimes. Delivery dates may fluctuate. Product exempt from discounts.
Product details
| Supply Voltage VDC: 12V |
| Fan Frame Type: Square |
| Fan Frame Size: 60mm |
| External Depth: 25mm |
| Bearing Type: Ball Bearing |
| Air Flow - CFM: 49.4CFM |
| Noise Rating: 53dBA |
| Power Rating: 8.04W |
| Rated Speed: 11000rpm |
| Power Connection Type: 4 Lead Wires |
| Current Rating: 670mA |
| IP Rating: IP68 |
| Air Flow - m3/min: 1.4m³/min |
| Product Range: San Ace 60W 9WL |
Other details
| Brand | SANYO DENKI |
| Part Number | 9WL0612P4S001 |
| Quantity | Each |
| Technical Data Sheet EN |  |
